12m3 Concrete Transit Mixer

Name: 12m3 Concrete Transit Mixer
Brand: UNIQUE
Availability: InStock

FOB Price

US$ 10,000 - 50,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Henan, China
Brand Name	UNIQUE	Model Number	UTTM6
Weight	4000kg	Dimension(LWH)	695025002820mm
Power(W)	180hp	Certification	ISO
Warranty	12 Months	After-sales Service Provided	Overseas service center available

Product Description

Specifications

Capcity: 12m3 Transit Mixer
Material: 6mm steel Sheet
Hydraulic Pump: Eton
Paint: Cat Painting techinic
Steel: Ball blast

UNIQUE Brand 12 m3 Truck Concrete Mixer

1. Unique 12m3 Concrete Truck Mixer

The concrete mixer is of middle capacity, self-falling type. It is suitable for mixing plastic and low-slump concrete. The aggregate size is required to be smaller than 60 mm.

The drum revolves for mixing and reverses for discharging.

2. Features of UNIQUE Concrete Truck Mixer

1) It adds Chinese or European famous hydraulic motor and pump and provide a powerfull function .

2) The high circularity of drum and advanced welding skills lead to discharge rapidly and remain few concrete. Moreover, it can transported more concrete compared with same model of others truck mixer.

It has the advantages of compact structure, higher reliability, mixing evenly, big capacity, easy operation, easily movable between sites, etc. The mixer is widely used in building site, road and bridge project, and many other construction sites.

3. Main Technical Specification

Model		4m³	6 m³	8 m³	12 m³
Mixer drum	Geometric volume	6.87 m³	9.78 m³	13.8 m³	18.6 m³
	Nominal volume	4m³	6 m³	8 m³	12m³
	Angle (°)	15	15	15	15
	Rolling speed	0~14r/min	0~14r/min	0~14r/min	0~14r/min
	Charging speed	≥3m³/min	≥3m³/min	≥3m³/min	≥3m³/min
	Discharging speed	≥2m³/min	≥2m³/min	≥2m³/min	≥2m³/min
	Residue rate	≤0.1%	≤0.1%	≤0.1%	≤0.1%
Hydraulic system	Pump	Chinese	Chinese	USA Eton Italy ARK	USA Eton or Italy ARK
	Motor	Chinese	Chinese	USA Eton or Italy ARK	USA Eton or Italy ARK
	Reducer	Chinese	Chinese	USA Eton or Italy ARK	USA Eton or Italy ARK
Water system	Method	Pneumatic supply (air pressure)	Pneumatic supply (air pressure)	Pneumatic supply (air pressure)	Pneumatic supply (air pressure)
Water system	Tank volume	180L	300L	400L	400L
Charge and discharge device	Material	16Mn steel plate	16Mn steel plate	16Mn steel plate	16Mn steel plate
Charge and discharge device	Device	Easy and multi-points operation	Easy and multi-points operation	Easy and multi-points operation	Easy and multi-points operation
Chassis	Chassis manufacturer	Shan Qi Bao Hua	Shan Qi Bao Hua	Dongfeng	HOWO
	Chassis type	4×2	4×2	6×4	6×4
	Fuel consumption	21 L/100km	22 L/100km	29 L/100km	29 L/100km
	Kerb mass	9300 kg	9300 kg	13300 kg	13300 kg
	Max. speed	80 km/h	80 km/h	80 km/h	80 km/h
	Max.gradability	30%	30%	30%	30%
	Max. rated total mass	14000 kg	15000 kg	24900 kg	24900 kg
	Rated load mass	9000 kg	9550 kg	11375 kg	11375 kg
	Wheel base	2800+1200 mm	3050+1250 mm	3650+1350 mm	3650+1350 mm
	Tread F/R	1700/1650 mm	1800/1750 mm	1986/1860 mm	1986/1860 mm
	Min. ground clearance	210 mm	210 mm	250 mm	250 mm
	Angle of approach/departure	28°/18°	28°/18°	28°/18°	28°/18°
Engine Parameters	model	YC4D130-33	YC6J180-33	L340 30	L340 30
	Displacement	6.2 L	6.2 L	8.9 L	8.9 L
	Emission standard	China 2	China 2	Euro 3	Euro 3
	Rated power	130HP	180HP	340HP	340HP
	Max.torque	1250/1100-1200 N.m/rpm	1250/1100-1200 N.m/rpm	1425/1200-1400 N.m/rpm	1425/1200-1400 N.m/rpm
	Fuel type	Diesel	Diesel	Diesel	Diesel
Overall Dimension		695025002820 mm	704026002950 mm	905024903820 mm	905024903820 mm

4. Delivery time

20~25 working days after the down payment.
