CG 700*500 Trough Feeder

CG 700*500 Trough Feeder thumbnail-1
CG 700*500 Trough Feeder thumbnail-2
CG 700*500 Trough Feeder thumbnail-3
CG 700*500 Trough Feeder thumbnail-4
CG 700*500 Trough Feeder thumbnail-5
CG 700*500 Trough Feeder thumbnail-6
CG 700*500 Trough Feeder photo-1
CG 700*500 Trough Feeder photo-2
CG 700*500 Trough Feeder photo-3
CG 700*500 Trough Feeder photo-4
CG 700*500 Trough Feeder photo-5
CG 700*500 Trough Feeder photo-6
US$ 1,000 - 3,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
ore feeding
Power Type:
Electric
Contact Supplier Request Quote Chat Now
Jiangxi Hengchang Mining Machinery Manufacturing Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen Guangzhou Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application ore feeding
Power Type Electric
Capacity(t/h) 10-60 t/h
Place of Origin Jiangxi, China
Brand Name Hengchang trough feeder
Model Number CG 700*500 trough feeder
Power(W) 4KW
Dimension(L*W*H) 700*500
Weight 1100Kg
Certification ISO and CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Hengchang CG series trough feeder for sale



1. Chute feeder can be installed on the ground or onto discharge port of ore bin.



2.  The chute bottom plates do the reciprocating movement, the movement frequency is 20-60 times/min and the stroke is 20-200mm.



3. Stroke can be adjusted by the eccentric wheel; the eccentric throw is half of the stroke.



4. According to experience of some mine sites, the eccentric throw should no less than 30mm for cohesive ore.


5. The chute width is 2-2.5 times of maximum feeding granularity.



6.  The biggest chute feeder can supply ore with granularity less than 500mm.



7.  The most common specification is 980 x 1240 chute feeder, with feeding granularity between 350-0mm, which is the best partner of 400 x 600 jaw crusher.



Specification of trough feeder

Specification

Max. particle size(mm)

Feed capacity(t/h)

Power

(kw)

dimension

L×W×H(mm)

Weight

(kg)

CG400×300

200

0-50

3

2820×800×600

792

CG400×400

100

2.5-3

4

2350×725×625

535

CG600×500

205

10.5-25.5

4

2750×910×855

1054

CG700×500

250

10-35

4

3200×950×900

1100

CG980×1240

350

36-90

7.5

3560×1000×1070

1700

CG1000×1900

300

300

7.5

3900×1590×1340

2691

CG1060×2900

300

400-900

25-40

4585×2953×1756

3260

CG1200×1000

400

165-415

15

3600×1357×1310

2600

CG1400×2000

300

50-101

7.5

3920×1777×1103

3472

CG1400×2300

300

430-900

18.5

4460×2090×3804

6895



CG 700*500 trough feederCG 700*500 trough feederCG 700*500 trough feeder

CG 700*500 trough feederCG 700*500 trough feeder
