Professional Supplier Desorption Electrolysis System , Factory Price Gold Mining Separator Processing Plant

Name: Professional Supplier Desorption Electrolysis System , Factory Price Gold Mining Separator Processing Plant
Brand: Xinhai
Availability: InStock

FOB Price

USD $10,000 - $500,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Qingdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, Desorption Electrolysis System
Production Capacity	depend on the model	Place of Origin	Shandong, China
Brand Name	Xinhai	Model Number	GKJD
Voltage	depend on the model	Power(W)	depend on the model
Dimension(LWH)	depend on the model	Weight	depend on the model
Certification	ISO 9001, CE	Warranty	one year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Professional Supplier Desorption Electrolysis System , Factory Price Gold Mining Separator Processing Plant

Our Desorption Electrolysis System can be used for many mineral grinding,such as gold ore,copper ore,iron ore and zinc ore and so on. When you find xinhai , you find the best mining machinery manufacturers. What you need is what we do.

Introduction

Gold Mining Separator Processing Plant —Product Introduction

A system obtains gold mud from carbon by desorption and electro winning

Gold Mining Separator Processing Plant —Gold Loaded Carbon Content

≥3.5kg/t

Product Structure

Gold Mining Separator Processing Plant —Product Structure

Desorption electrolysis system consists of desorption column and the electrodeposition tank

Product Advantages

Gold Mining Separator Processing Plant —Advantages

In the high temperature (150ºC) and pressure (0.5MPa), the desorption rate reaches 98%

Since desorption and electrolysis does not require different temperatures, it is not necessary to change temperature. The quickness and efficiency of machine dramatically diminishes gross electricity consumption by 1/2-1/4.

Desorption does not require sodium cyanide, which reduces cost and averts pollution.

Working principle

Gold Mining Separator Processing Plant —Work Principle

When the desorption system is added with anions which are more easily absorbed by activated carbons, Au(CN)2 is replaced by anion and the gold desorption is achieved. After the carbons loaded with gold are desorbed, pregnant solution is process via ionization. At last, solid gold is attained.

Product Improvement

Gold Mining Separator Processing Plant —Relative Equipment

The analytical column, electrolytic tank, filter, heater, analytical solution agitation tank, control electric wheel, DC power supply, measuring instrument

Technology parameter

Gold Mining Separator Processing Plant —Parameter

Model	Suitable Scale		System Equipment List	System Instrument List	Operation Parameters
	Mine Scale(t/d)	Crude Ore Grade(g/t)
GKJD- 200	<150	2-8	JXZ desorption column GLQ Filter Electrolysis Tank CQ Circulation Pump DRQ Electric Heater W Air Compressor PYC Desorption Solution Tank XL Control Cabinet GDF Rectifier Cabinet	Resistance Remote Transmitting Diaphragm Pressure Gauge Pressure Indicator Diaphragm Pressure Gauge Vortex Flow Meter Flow Totalizer Thermal Thermometer Temperature Sensor Level Instrument Temperature Indication Accommodometer	Temperature:150±2OC PH:≥13.5 Flow:2.4m3/h Current:300±100A Voltage:2-4V Power:75.6(KW) Desorption Tank Pressure:0.5-0.57(Mpa) Electrolytic Tank Pressure:0.45-0.52 (Mpa)
GKJD-300	150-300
GKJD-500	300-500
GKJD-700	500-750
GKJD-900	750-1000
GKJD-1000	1000-1500
GKJD-1200	1000-1500
GKJD-1500	>1500

Xinhai Group

Xinhai mining was established in 1993.And was the pioneer of China beneficiation industry.Our company could provide mining machine more than 600,and have the most equipment in China.At present,Xinhai business includes Mineral Processing EPC,Wear-Resistant Rubber,LFC Machinery,and Mining Investment.

this is our factory and our office building.

this is our laboratory and laboratory data.

Our customers come from all over the world, such as Xinhai EPC project ,Africa Mail 800t/d gold; Xinhai Transformation Project, Indonesia PT.NEM Gold Mine as so on. We have a lot of successful cases in America, Russia and Africa .Also we have Zimbabwe Office,Sudan Office and Indonesia Office. We will give you the best service.

this is our project in Africa.

Q:Hi, are you mining machinery manufacturer?

A:Yes, we can also provide amples test, mine design, equipment manufacture, after-sale service, etc.

Q:which country have your products been exported?

A:Many country, such as India, Ethiopia and so on. And our company has agencies in Zimbabwe, Sudan and Tanzania.

Q:Can you do mineral processing test?

A:Yes, not only can do it in your country, also can back to our company
