Specifications
pallets stretch film wrapping machine1.integrated control system
2.adjustable speed
3.human-computer interface
4.stable
pallets stretch film wrapping machine
I. Introduction of the pallets stretch film wrapping machine :
T series pallet wrapping machine is used in the packing of the pallet or transport of big-scale containers.
It is widely used in the fertilizer products, glass products, paper industry, chemical industry , food and beverage industry and building material industry. It can increase the transporting efficiency, decrease the loss in the transporting process and lower the cost.
II. Specifics of the pallets stretch film wrapping machine :
1. Control system
- The control system and the machine are integrated
- The layers and the wrapping time can be setted
- Photoelectric switch can measure the height of the goods automatically.
- Strengthening palletizing function, it can protect some certain parts.
- Overtopping time set function
2. Turntable driving system:
- The turntable speed can be adjusted from 0-12 rpm by frequency changing system.
- The turntable is drove by chain and makes it accurately located.
- The turntable can reset automatically.
- The bottom of the turntable is equipped with channel for forklift.
3. The film stretching system:
- Film pre-stretching stand can pre-stretch by 250%-300%, and feed the film automatically. The speed adjustable DC motor can control the tension of the wrapping film.
- Double-chain system, stable and reliable.
- The rising and lowering speed and the film feeding speed of the film stretching stand can be adjusted
- The top and bottom wrapping number is controlled separately.
- Film follow-up mechanism
4.human-computer interface
- Easy to set data
- Clean operation board
- It can satisfy customers with different function requirement
- It can show the impediment and count the quantity.Makes it easier to remove impediment
III. Technical parameters of the pallets stretch film wrapping machine
Model |
T1650F |
|
Max loading size |
(500-1200)x(500-1200)mm |
|
Loading height |
800-1800mm |
|
Packing efficiency |
20-40 loads / hour |
|
Turntable speed |
0-12rpm |
|
Turntable diameter |
1650mm |
|
Turntable Height |
77 mm |
|
Turntable weight capacity |
2000kg |
|
Machine weight |
700kg |
|
Power supply |
220V/ 50HZ /20A 1Phase (standard) |
|
Material |
LLDPE - Stretch Film |
|
Power |
Turntable |
0.75KW |
Film stand |
0.4KW |
|
Vertical post |
0.37KW |
|
