High Efficiency Solar Thermal Collector of White Frame,laser Welding
US$ 110 - 125
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
sinoyin
Place of Origin:
China
Model Number:
FP-GV2.0-80-W
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
10 days
Related Products
-
High Efficiency Solar Thermal Collector of White FrameUS$ 110 - 125MOQ: 1 Piece -
High Efficiency Solar Thermal Collector of Black FrameUS$ 110 - 125MOQ: 1 Piece
-
High Efficiency Solar Thermal Collector of 2.5sqm,black FrameUS$ 130 - 145MOQ: 1 Piece
-
High Efficiency Solar Thermal Collector of 2.0sqm,black Frame,grid AbsorbersUS$ 110 - 125MOQ: 1 Piece
-
High Efficiency Solar Thermal Collector of Black Frame,high Efficiency AbsorberUS$ 115 - 130MOQ: 1 Piece
Brand Name
sinoyin
Place of Origin
China
Model Number
FP-GV2.0-80-W
Type
Flat Panel
Application
Solar Thermal
Pipe Material
Copper
Product Description
| Collectors Specifications | |||||
| FP-GV2.0-80-LT | FP-GV2.0-80-HG | ||||
| Dimensions | 2000X1000X80mm | 2000X1000X80mm | |||
| Casing material | aluminum alloy 6063-T5 | aluminum alloy 6063-T5 | |||
| Gross area | 2.0m2 | 2.0m2 | |||
| Aperture area | 1.823m2 | 1.823m2 | |||
| Absorber coating | magnetron sputtering coating,thickness0.4mm; | chromeplate coating ,thickness0.4mm; | |||
| Absorptance | ≥95% | ≥93% | |||
| Emittance | ≤5% | ≤10% | |||
| Welding Method | laser welding | laser welding | |||
| Heat carrier volume | 1.2L | 1.2L | |||
| Head tube | diameter:φ22mm,thickness:δ0.6mm | diameter:φ22mm,thickness:δ0.6mm | |||
| Branch tube | diameter:φ8mm,thickness:δ0.6 | diameter:φ8mm,thickness:δ0.6 | |||
| Weight | 34Kg | 34Kg | |||
| Insulation material | fiber glass,thickness,30mm | fiber glass,thickness,30mm | |||
| Glass cover | low iron tempered,thickness:3.2 | low iron tempered,thickness:3.2 | |||
| Efficiency(η) | 0.77 | 0.75 | |||
| Heat loss | 4.5W/m2.℃ | 4.5W/m2.℃ | |||
| Stagnation temperature | 180℃ | 165℃ | |||
| test pressure | 1.2Mpa | 1.2Mpa | |||
| Normal pressure | 0.7Mpa | 0.7Mpa | |||
| Recommend flow rate | 70-80L/h | 70-80L/h | |||
| Recommend connecting number | ≤8 | ≤8 | |||
| Packaging | Corrugated carton | Corrugated carton | |||
| Warranty period | 5 years | 5 years | |||
| 20 feet container num: | 140Pcs | 140Pcs | |||
| 40 feet container num: | 312Pcs | 312Pcs | |||
Product details show
Product details show:
Advantages
Advantages:
Office show
Office show:
manufacturing shop
Mamufacturing shop:
Certifications:
Certifications:
Packaging
Packaging:
Product Uses
Product uses:
