Used rotary sand dryer,industrial dryer,rotary drum dryer High density material drum dryer has good performance with reliable operation,good flexibility
and adaptability,large drying capacity.Drum dryer is suitable for granular material. Especially in
drying of sand,drum dryer has excellent dry results.High density material drum dryer usually is used
for drying river sand,artificial sand,quartz sand,mine power,cinder,slag,etc.
Applications
Applicable for drying big particles, heavy particles in chemical, mining, and metallurgy, such as mining area, cinder of blast furnace, coal, powder of metal, phosphate fertilizer and thiamine.
For drying the powder or particles with special requirements, such as HP foaming blowing agent, residule of alcohol, light calcium carbonate, active clay, magnetic powder, graphite, and residue of medicine. For materials to be dried under low temperature and large lot continuous production
Features
The motorization level of the barrel is high, and the production capacity is high.
The resistance that the material passes through the barrel is less, and the power consumption is low.
Application capability to different characters of materials is high.
The operation is stable, the operation fee is low, and the uniformity of product drying is good.
Main technical parameters
Model(mm) |
Gradient (%) |
Rotating speed (r/min) |
Temperature (°C) |
Power (kw) |
Capacity (t/h) |
Weight (t) |
XSZ-600 |
3-5 |
3-8 |
≤700 |
3 |
0.5-1.5 |
2.9 |
XSZ-800 |
3-5 |
3-8 |
≤700 |
4 |
0.8-2.5 |
3.5 |
XSZ-1000 |
3-5 |
3-8 |
≤700 |
5.5 |
2.0-4.5 |
5.6 |
XSZ-1200 |
3-5 |
3-8 |
≤700 |
7.5 |
4-8 |
14 |
XSZ-1500 |
3-5 |
2-6 |
≤800 |
15 |
8-15 |
17.8 |
XSZ-1800 |
3-5 |
2-6 |
≤800 |
18.5 |
10-18 |
25 |
XSZ-2000 |
3-5 |
1.5-6 |
≤800 |
18.5 |
15-22 |
36 |
XSZ-2200 |
3-5 |
1.5-6 |
≤800 |
22 |
18-25 |
53.8 |
XSZ-2400 |
3-5 |
1.5-5 |
≤800 |
37 |
22-35 |
|
XSZ-3000 |
3-5 |
1.5-5 |
≤800 |
75 |
32-45 |
87.5 |
Note:the capacity has much to do with the heating mode for the dryer | ||||||
....
