Vegetable and Fruit Dehydration Machine /conveyor Mesh Belt Dryer

Vegetable and Fruit Dehydration Machine /conveyor Mesh Belt Dryer thumbnail-1
Vegetable and Fruit Dehydration Machine /conveyor Mesh Belt Dryer photo-1
US$ 5,000 - 500,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, mesh belt dryer
Place of Origin:
Henan, China
Contact Supplier Request Quote Chat Now
Zhengzhou Yufeng Heavy Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, mesh belt dryer
Place of Origin Henan, China
Brand Name YUFENG
Model Number HJWD6/HJWD8/HJWD10/HJWD12/HJWD16/HJWD20/HJWD24/HJWD30
Voltage 220v/380v/480v
Power(W) 1.1/2.2/3/1.5/4/7.5/5/11
Weight carrying capacity 90-200kg/㎡
Certification ISO9001:2008
Warranty 2 years (except the easy-damaged parts)
After-sales Service Provided Engineers available to service machinery overseas

Mesh belt dryer

Mesh belt dryer is a kind of batch,continuous production drying equipment,its mainly heating solution includes electric heating,

steam heating and hot air heating.The mesh belts are made by 12-60 mesh steel wires.The main principle is that the materials is spread uniformly on the mash-belts,transmission device will drive the meshbelt into reciprocating movement inside the dryer.Meanwhile,the hot air will flow

and touch the wet materials,the evaporating steam will be discharged into air by special site,the dryer can be made into all the

steam ar discharged,the material will achieve the purpose of drying.In order to save the project site,the dryer can be made into

multi-layers.The widely used dryer is 2 rooms with three layers or 2 rooms five layers,length is 6-40 m,effective width is 0.6-3.0 m.

Vegetable and fruit Dehydration machine /conveyor mesh belt dryerVegetable and fruit Dehydration machine /conveyor mesh belt dryer

Vegetable and fruit Dehydration machine /conveyor mesh belt dryer

Main technical data



Sec.



HJWD6

HJWD8

HJWD10

HJWD12

HJWD16

HJWD

20

HJWD24

HJWD30

Band width(mm)

600

800

1000

1200

1600

2000

2400

3000

Dry section length(m)

6-12

6-12

6-16

8-16

8-22

10-26

12-30

12-40

Feeding length(m)

1

1

1

1

1

1.5

1.5

2

Transmission section length

1

1

1

1

1

1.5

1.5

2

Dry area

3.6-36

4.8-48

6-80

7.2-96

12.8-105.6

20-260

28.8-360

36-600

layer

1-5

Layer spacing(mm)

400-600

Carrying capacity

90-200kg

Using temperature

Carbon steel≤400°C,stainless steel≤600°C

Evaporation strength

5-20kg water/.h

Heat source

Hot air.electric.steam

Operation speed

0.06-1m/min

Transmission power(kw)

1.1-2.2

1.1-2.2

1.1-2.2

1.1-3

1.5-3

1.5-4

3-7.5

5-11

Auxiliary equipment

Transportation equipment,hot air stove,dust removal equipment,induced draft fan,etc

 Vegetable and fruit Dehydration machine /conveyor mesh belt dryer

...
