Specifications
Specification1.loading capacity:3000kg
2.tare weight:1000kgs
3..matched power:18-40HP
4..size and color: as you need
Hydraulic Dumper Trailer
1.Product Show
2.Specification
| Model | 7CX-3 |
| Carriage size | 3000*1600*500mm |
| Overall size | 4500*1650*1750mm |
| Loading capacity | 3000kg |
| Tare weight | 1000kg |
| Tire NO. | 2 |
| Brake | air brake or hand brake |
| Matched power | 25-40hp |
| Discharge form | hydraulic tipping |
| Size and color | can customized |
3.Introduction
Product features: 3 tons of trailers generally have 2 or 4 wheels, supporting dynamic 25-40hp, brake using gas-filled brake. self discharge could choose as you need. 3 tons of two-wheel self discharge is tipping back, 4 wheel self discharge is taken over in the form of bilateral, 4 wheel vehicle equipped with the circuit. Suitable for carrying goods in the short distance transportation and field work.
The form of turning: centreless turntable.
The form of damping: elastic arch board.
The form of traction: tripod stand traction.
The dump configuration: dual cylinder. Rear taillight, around the fence. whole vehicle wiring .
Gas path connection: pipe fast joint.
Circuit connection: spiral seven core lines quickly plug.
The oil circuit connection form: quick change joint.
Surface treatment: large shot blasting machine to eliminate welding stress, derusting, descaling, antirust paint, finish painting, backing finish handling.
Welding process: CO2 tooling welding.
Mode of transport: spare parts transportation, container board packed with flexible package
Hi, we are a manufacturer in China for years, we can produce all kinds of trailers. And we also accept OEM and ODM. If you want to know more information or have any question, please feel free to contact me.
Skype:sarahzhang310
4.Certificate
5.Contact me
