farm tractor mounted boom sprayerSPRAYER:
1.TANK CAPACITY:600L
2.SPRAY WIDTH : 10m
3.No.OF SPRAY HEAD:20PCS
Tractor Boom Sprayer
1.Product Show
2.Main Specification of BOOM SPRAYER :
As a utility model rod-spray machine hung onto roller tractor, this 3W Series suspended type rod spray machine owns many advantages, such as flexible use,simplified operation and alike, so it is suitable for the extermination of disease and insect pest of crops,foliar nutrient and weedicide spray. For the pipelines of machine, adopt special anti-corrosive material so that a excellent corrosion-resistance performance, in addition, adopt double-cylinder membranous pump for fluid pump in order to acquire stable working pressure and even spray, also the height of spray-rod can be regulated as required so that it is convenient for the operation by driver of tractor.
And only the anti-drop spray-head can be used for sparging component in case there is any residual liquid medicine dropping from pipeline.
Number | Product Name | Model | Matched Power (Hp) | Weight (Kg) | Working width (M) | volume L | Nozzles | Nozzles spacing (mm) | Packaging System |
1 | sprayers | 3W-200-6 | 15-30 | 120 | 6 | 200 | 12 | 500 | Iron cages |
2 | sprayers | 3W-400-6 | 20-40 | 150 | 6 | 400 | 12 | 500 | Iron cages |
3 | sprayers | 3W-400-10 | 20-40 | 160 | 10 | 400 | 20 | 500 | Iron cages |
4 | sprayers | 3W-500-10 | 25-50 | 280 | 10 | 500 | 20 | 500 | Iron cages |
5 | sprayers | 3W-650-10 | 65-80 | 310 | 10 | 650 | 20 | 500 | Iron cages |
6 | sprayers | 3W-1000-10 | 70-100 | 330 | 10 | 1000 | 20 | 500 | Iron cages |
7 | sprayers | 3W-500-12 | 25-50 | 300 | 12 | 500 | 24 | 500 | Iron cages |
8 | sprayers | 3W-650-12 | 65-80 | 330 | 12 | 650 | 24 | 500 | Iron cages |
9 | sprayers | 3W-1000-12 | 70-100 | 350 | 12 | 1000 | 24 | 500 | Iron cages |
10 | sprayers | 3W-1000-14 | 70-100 | 400 | 14 | 1000 | 28 | 500 | Iron cages |
3. Package
4.Contact Us
Hope you can give me the enquiry and order , i will give you the best price and high quality goods.
