Russia high pressure split solar water heater

FOB Price

Negotiable / Set

1 Set(Min.Order)

Port Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	Sky Genius
Model Number	SGRB	Specification	Normal
Application	Home	Output Voltage (V)	220V
Solar Power (W)	800W / m2	Work Time (h)	72

Product Description

split solar water heater

A 50/50 propylene glycol and water mixture from the collectors through a coil of pipe in the solar tank, and then is pumped back through the collectors. The potable water is warmed by heat transfer through contact with the pipe. These systems are pretty much the only choice in very cold climates. When there is not enough energy for sun, an electrical or gas back up element will be automatically switched on by controller.

1.Simple Installation, no maintenance, effective operation
2.Easy retrofitting to existing systems
3.Suitable for single and multiple solar heating application systems
4.Preferred option for extremely cold areas and questionable water quality
5.Incoming potable water is routed to the solar storage tank
6.Porcelain enamel or SUS316 stainless steel storage tank with electrical or gas back up
7.Double-walled copper coil heat exchangers in storage tank prevent contamination of household water

Tank model	100L	150L	200L	250L	300L	400L	500L
Inner tank diameter(mm)	φ370	φ370	φ470	φ470	φ470	φ600	φ600
Water tank diameter(mm)	φ470	φ470	φ560	φ560	φ560	φ700	φ700
Material and thickness of the inner tank(mm)	Stainless steel 304 1.2mm	Stainless steel 304 1.2mm	Stainless steel 304 1.5mm	Stainless steel 304 1.5mm	Stainless steel 304 1.5mm	Stainless steel 304 2.0mm	Stainless steel 304 2.0mm
Material and thickness of the outer cover(mm)	Galvanized Steel 0.55mm	Galvanized Steel 0.55mm	Galvanized Steel 0.55mm	Galvanized Steel 0.55mm	Galvanized Steel 0.55mm	Galvanized Steel 0.55mm	Galvanized Steel 0.55mm
Insulation thickness(mm)	55mm	55mm	55mm	55mm	55mm	55mm	55mm
copper coil inlet & outlet diameter	1/2 inch	1/2 inch	1/2 inch	1/2 inch	1/2 inch	1/2 inch	1/2 inch
inlet & outlet diameter	3/4 inch	3/4 inch	1 inch	1 inch	1 inch	1 inch	1 inch
Heat-exchange area of upper coil(m2)	(none)	0.4	0.4	0.4	0.4	0.5	0.5
Heat-exchange area of bottom coil(m2)	0.6	0.6	0.6	0.7	0.7	0.8	0.8
Subsidiary heating power	2.0 KW	2.0 KW	2.0 KW	2.0 KW	2.0 KW	3.0 KW	3.0 KW
Overall dimension(mm)	*φ4701040**	*φ4701440**	*φ5601250**	*φ5601520**	*φ5601810**	*φ7001540**	*φ7001850**
Packing size(mm)	*5505501120*	*5505501500*	*6406401330*	*6406401580*	*6406401870*	*7807801630*	*7807801950*
Weight (Kg)	34	48	55	60	69	78	100

Certificate: SRCC, CE, ISO9001, Solar Keymark
