Home > Metallurgy, Mineral & Energy > Solar & Renewable Energy > Solar Controller > SR609 Solar Water Heater Controller
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Sky Genius
Model Number:
SR609
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SP24 Solar Water Heater ControllerNegotiableMOQ: 1 Set -
SR961 Solar Station for Split Solar Water HeaterNegotiableMOQ: 1 Set
-
SR962 Solar Station for Split Solar Water HeaterNegotiableMOQ: 1 Set
-
SR500 Solar Water Heater ControllerNegotiableMOQ: 1 Set
-
2016 Split Portable Solar Powered HeaterNegotiableMOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
Sky Genius
Model Number
SR609
Application
Water Heater Controller
Rated Voltage
Other, 220V
Maximum Current
9A
SR609 solar water heater controller
Introduce
suitable for intergrated pressurized solar system
Main technical data
- Appearance of controller: see product itself ( dimension: 179mm x120mm x43mm)
Power supply:AC230V ±10%
Power consumption:< 3W
Accuracy of temperature measuring: ± 2oC
Range of tank temperature measuring: 0 ~100oC
Suitable power of electrical heater, ≤ 2000W
Inputs: 1 piece NTC10K, B3950 sensor (≤ 135oC) for tank, (PVC cable ≤105oC),
Outputs:1 relay, for electrical heating
Ambient temperature :-10oC~ 50oC.
Water proof grade:IP40.
Main functions
- Time display
Temperature display
Timing heating at three time sections
Manual heating
Memory protection when power is failure
Trouble indication of sensor
System
Certificate: SRCC, TUV, CE, ISO, Solar Keymark
