CE Ram-type biomass briquetting machine
> Ram-type Wood Briquette Machine not only can produce wood briquette,but also can produce wood pellet 8 or 10mm, and has advantage of unique design, easy operation, low consumption but high efficiency,because the wearing parts (Die) cost very low,so production cost very low.
> Ram-type Wood Briquette Machine Raw Materials:
Crop stalks (including cornstalks cotton stalks ),grain shell(rice husk ) ,peanut shell and stalks, cotton stalks,
sawdust,branch,bark ,bamboo powder, furfural residue(could be mixed used), Wood scraps ,Forest harvesting
slash, household refuse,scraps produced by paper making factory,all of these could be smashed and briquetting.
> Ram-type Wood Briquette Machine Main Technical Parameters:
| Ram Type Wood Briquette Machine | |
| Main Power | Main Power 45kw,Total 60.35KW |
| Frequency Conversion Screw Conveyor | 1.5kw*2pcs |
| Sawdust Distributor | 0.25kw(Single-phase) |
| Left and Right feeding conveyor | 5.5kw*2pcs |
| Oil Pump |
1.1kw |
| Electric Control Cabinet |
1 pcs |
| Production Capacity | 0.8-1.5T/h |
| Final Briquette or Wood Pellet Diameter | 8,10,22,30,40,50,60,70,80,85mm |
| Density of Briquette or Wood Pellet | 1-1.3g/CM3 |
| Feeding Raw Materials Size | Less than or equal to 30mm |
| Raw Materials Moisture Content | 10-20% |
| Density of Briquette or Wood Pellet | 1-1.3g/CM3 |
| Briquette Moisture Content | Less than or equal to 12% |
| Machine Size(L*W*H) | 3.4*2*1.8M |
| Machine Weight | Total weight 8Ton |
| Wearing Parts Die Life | 100-400Hour,Low Price |
> Ram-type Wood Briquette Machine Working Priciple:
The machine get reciprocating motion by pulley driven by eccentric wheel, and then the feeder machine will
start to feeding. Then the raw material go through distributor to get into the feeding box on the briquetting
machine, and the next step is from feeding box to molding machine by the appending machine from two sides .
Under the pressure caused by punch and molding die ,the raw material become heating up and softened ,and the
volume become smaller. Then the raw material get solid and being extruded by molding die with reducing taper
due to repeated impact .
Pellet shaping process is effected by pressure and temperature ,so the operation principle is punch principle ,
the machine carry punch 280 times /min when it works normally. The pressure will up to 300T and the
temperature is 150-200°C, so the equipment could be used widely for so many kinds of raw material and enjoying a excellent forming density. In addition ,all parts of the equipment lubricated forced by
the Oil pump lubrication system to ensure the equipments enjoy a longer service time.
To know more, pls contact
