Hot Selling Sieve for Biomass and Feed Pellets
Application of Hot Selling Sieve for Biomass and Feed Pellets:
It is very useful in pharmaceutical, plastics, rubber, ceramic, food, chemical, fertilizer, glass industries. Vibratory screen can be provided with dust proof cover as required.
Features of Hot Selling Sieve for Biomass and Feed Pellets:
1. It is equipment which classifies mixtures with various particle sizes through vibrating screen;
2. Self balancing is adopted for driving. There are two vibrating motors mounted on screener hull symmetrically, which rotation direction is contrary to ensure screening effect;
3. It is small space occupying, stable and widely used.
Working principle of vibrating classification screen
The vibration screen is driven by two vibration motors. When the two vibration motors are performing reserve rotation synchronously, the exciting force generated by the eccentric block will compensate each other in the direction parallel to the axis motor and combine with each other as joint force. Therefore the movement curve of screen is liner one. There is one dip angle on the relative screen surface of the two motor axes. Under the impact of joint force by exciting force and self-gravity force, materials will be tossed up for forward leap liner movement so as to realize material screening and classification.
Main performance and technical parameters:
Model |
MFJZ80*2 |
MFJZ100*2 |
MFJZ125*2 |
Capacity(t/h) |
3-5 |
6-10 |
8-12 |
Power(kw) |
0.37*2 |
0.37*2 |
0.37*2 |
Products exhibitions:
We can provide the screener by automatical screener(with two motors) and simple structure sifter(without motors).
Advantages of Hot Selling Sieve for Biomass and Feed Pellets
1. Three moving modes i.e. circumferential, elliptical and rectilinear are combined, resulting in good screening effect.
2. The strengthed base ensures that equipment will run more smoothly. And the hanging structure can be used according to the actual site conditions so as to meet customers' requirement of retrofit.
3. The improved steel cable structure avoids wearing of steel cable.
4. The adoption of one body or combined screener cover structure guarantees lower screener covers weight, stronger rigidity and better sealing.
5. It is applicable for screening and classifying of mash or pellet. It can also be used for cleaning of raw materials and classifying of semi finished products after second grinding by large and medium mills.
Liangyou corner:
Typical project:
Quality certification:
Packing & delivery:
WHY CHOOSE US?
Our products have passed the SGS, ISO9001: 2008, CE certifications. Moreover, we own several patents, such as "utility model patents certificate"and "high-tech products certificate", etc. Our goods exported to many countries and won the good reputation by the high quality and superior service.
