Super Fine Zinc Powder Production Vacuum Distillation Furnace

Super Fine Zinc Powder Production Vacuum Distillation Furnace thumbnail-1
Super Fine Zinc Powder Production Vacuum Distillation Furnace thumbnail-2
Super Fine Zinc Powder Production Vacuum Distillation Furnace thumbnail-3
Super Fine Zinc Powder Production Vacuum Distillation Furnace photo-1
Super Fine Zinc Powder Production Vacuum Distillation Furnace photo-2
Super Fine Zinc Powder Production Vacuum Distillation Furnace photo-3
US$ 0.1 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, vacuum distillation furnace
Usage:
Other, distillation furnace
Contact Supplier Request Quote Chat Now
Unionsum International Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, vacuum distillation furnace
Usage Other, distillation furnace
Place of Origin Hunan, China
Brand Name unionsum
Voltage 380V
Power(W) Adjustable
Dimension(L*W*H) Custom Made
Weight 2T-35T
Certification ISO
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Zinc residue recovery vacuum distillation furnace



Product Description

Vacuum distillation furnace is a newly developed distillation furnace by Unionsum.Now it is widely used by customer to recover Sn, Sb, Bi, Ag, and Cd from drosses from refining process, slag, Lead eletro-refining anode slime, Copper eletro-refining anode slime and so on. Its main power is that it can separate Sn, Zn, Ag, Pb and Sb from each other when they are in the alloy.

Super fine Zinc powder production vacuum distillation furnace



Working principle

Decrease boiling point of metals in alloy under vacuum condition to distil & purify each low boiling point(≤2000°C) metal from alloy and leave & purify high boiling point metals Produce liquid metal or nanoscale powder by control of the condensation speed.

Application field
  • Bi-Ag-Zn slag, Pb-Ag-Zn slag distillation

Bi-Ag-Zn slag, Pb-Ag-Zn slag from adding Zn to removal Ag process for Bi /Pb fire-refining process can go through vacuum distillation process to separate Bi-Zn or Pb-Zn from rich Ag residue.

  • Pb/Cu floating slag treatment

Pb/Cu floating slag from Cu removal process for Pb (95~98%) fire-refining can go through vacuum distillation process to separate Pb from Copper matte (Pb≤2%).

  • Ag recovery from Lead anode slime and Copper anode slime

Pb anode slime with precious metal (Au/Ag), or crude rich Lead from reduction smelting, can be through vacuum distillation process to separate Pb/Sb/Bi from rich Au/Ag residue.

  • Pb secondary material distillation

Pb secondary material can go through vacuum distillation process to separate Pb/Sb/Bi from Sn/Cu/Ag/Au residue.

  • Spent Cd-Ni battery pollution-free recycling

Cd-Ni batteries can go through comprehensive process to produce stainless steel and Cd ingot (99.998%).

  • High pure Zn ingot distillation

Zn ingot (98%) can go through distillation process to produce high pure Zn ingot (99.999%).

  • Valuable metals enrichment from hard Zinc

Hard Zinc can go through distillation process to produce Zn (99.5%), remove Fe / Pb, and enrich Ag/Ge/Im.

  • High-pure super-fine Zn powder

Zn (90~99%) can go through distillation process to produce high-pure super-fine Zn powder (99.99%, 2~15μm).

  • Hot galvanizing Zn residue distillation

Hot galvanizing Zn residue (Zn/Fe/Al alloy) can go through distillation process to produce Zn ingot/powder (99.99%) and Al residue.

  • Example process Super fine Zinc powder production vacuum distillation furnace
Advantages
  • Low energy consumption, 600~800kwh/MT raw materials
  • High purity of metal product, ≥99.95%
  • Can produce liquid metal and solid metal powder
  • Large capacity, single furnace 10t/d, continuous or batch shift
  • No off-gas, environmental friendly, hygiene working
  • Automatically operation
  • Low infrastructure cost, less construction area
Customized services

Customized vacuum distillation test before order

Korean customer                                                                                Indian customer

Super fine Zinc powder production vacuum distillation furnace         Super fine Zinc powder production vacuum distillation furnace

Russian customer                                                                               Bulgaria cusomter

Super fine Zinc powder production vacuum distillation furnace         Super fine Zinc powder production vacuum distillation furnace

Unionsum Experts at oversea site

Super fine Zinc powder production vacuum distillation furnace

Equipment Test at factory before delivery

Super fine Zinc powder production vacuum distillation furnace

Company Information

Super fine Zinc powder production vacuum distillation furnace                                           Prospecting                                                      Mining                                                         MetallurgySuper fine Zinc powder production vacuum distillation furnace                                         Processing                                                       Trading                                                             EPC serviceSuper fine Zinc powder production vacuum distillation furnace

Unionsum, a subsidiary of CRIMM, provides sustainable system solution for mining and

metallurgy industry, including engineering, procurement and construction, and offers a widerange of

scientific research and consultingservices.





 Clients Visiting



Super fine Zinc powder production vacuum distillation furnace Global Market

Super fine Zinc powder production vacuum distillation furnace                                           Vacuum distillation project at Bulgaria                                          Rotary Furnace at Thailand
