Plastic Structured Filter for Atmospheric Distillation
- Shenzhen Shanghai and any port in China
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Jiangxi, China | Brand Name | ZY | |
| Model Number | X6793 | Plastic Modling Type | Blow Molding |
Product Description
Specifications
1)20 years professional manufacture2)High quality and reasonable price
3)Ontime delivery
4)One-stop service
5)ISO9001:2000
The plastic structured packing has the characteristic of light weight, big flow, low drop pressure, large specific surface area, easy change etc. The plastic gauze corrugated packing is made of PP and polyacrylonitrile line. Also the plastic corrugated plate packing is assembled PP, PVDF and PVC material.
Technical data
| Type | Surface area (m²/m³) | Bulk density (kg/m³) | Void space % | Nt M-1 | P Pa/m | Max. F-factor M/s.(kg/m3)0.5 | Liquid load M3/m2.h |
SB-125Y | 125 | 37.5 | 98.5 | 1.0-2.0 | 200 | 3 | 0.2-100 | |
125X | 0.8-0.9 | 140 | 3.5 | |||||
SB-250Y | 250 | 75 | 97 | 2.0-2.5 | 300 | 2.6 | ||
250X | 1.5-2.0 | 180 | 2.8 | |||||
SB-350Y | 350 | 105 | 95 | 3.5-4.0 | 200 | 2.0 | ||
350X | 2.3-2.8 | 130 | 2.2 | |||||
SB-500Y | 500 | 150 | 93 | 4.0-4.5 | 300 | 1.8 | ||
500X | 2.8-3.2 | 180 | 2.0 | |||||
Note: The above data is for reference only. | ||||||||
