High Quality Light Ceramic Structured packing

Specifications

1)20 years' professional manufacture
2)Good quality and favorable price
3)Fast delivery and best service
4)ISO9001

Introduction:

Light ceramic packing special suit for washing benzene tower and the desulfurizer specialized packing,light ceramic packing which has light bulk density ,large surface area,low resistance ,can incise ,high temperature resistance and anti-corrupting.It is widely used in coking industry to washing benzene,washing ammonia,decarbonization ,desulfurizing and so on.



Characteristics:

1)light ceramic packing has a light bulk density and low resistance. The density of multi-pore packing is 1.04g/cm3 and the specific gravity of one pile is 0.4g/cm3, which is much lower than for ceramic and metal packing. Thus it has the advantage of being light weight.

2) light ceramic packing has a large mass-transfer coefficient, large valid area and excellent effectiveness. Tests conducted by Tianjin University have shown that the coefficient of multi-pore packing is 2.2 times higher than holo-ceramic packing.

3) light ceramic packingcan resist aging, sudden heat and sudden coldness. Its fire-proofing rate is 1400oc , and it is acid resistant, thus can be used for a long time and is not easily aged.

We have  Environment-friendly 6-ribbed ceramic ring, Light Multi ceramic ring,  Light-ribbed Bar-crossed ceramic ring and  Light Corrugated-grating ring.

Main Specification:

Products	Types	Opposite side distance mm	Height Mm	Aperture mm	Specifica surface area m2/m3	Void volume %	Heaping weight Kg/m3
Environment-friendly 6-ribbed ceramic ring	ZY001	220±2.5	110±1.5	65±1.5	99±2	72±2	390±25
Light Multi ceramic ring	ZY002	220±2.5	110±1.5	65±1.5	132±2	75±2	320±25
Light-ribbed Bar-crossed ceramic ring	ZY003	220±2.5	110±1.5	65±1.5	124±2	69±2	325±25
Light Corrugated-grating ring	ZY004	220±2.5	110±1.5		138±2	78±2

 Chemical Composition:

SiO2	Al2O3	Fe2O3	CaO	MgO	K2O	Na2O	TiO2	Ignition Lost
≥65%	6-12%	≤2.0%	≤2.5%	≤2.1%	≤1.8%	≤0.1%	0.33%	0.48.

 Physical Properties:

Thermal resistance					Acid resistance%	Alkali resistance %	Solubility resistance %	Crushing Strength	Thermal stability  200 °C
Acid medium		Alkali medium		Neutrality medium
strong acid	infirm acid	strong alkali	infirm alkali	900°C	99	82	100	>8MPa	Thermal shock resistance >5
-20°C~150°C	300°C	-20°C~30°C	200°C



Advantages:

A. light specific gravity and low obstruction. B.a large mass-transfer co-efficient, large valid area and excellent effectiveness. C.resist aging, sudden heat and sudden coldness. D.a new structure that can make circular shapes, is able to be cut and easy to pack.
