Home > Products > Ceramic Brick > cheap porcelain plate,ceramic plate
cheap porcelain plate,ceramic plate
- 1000 Long Ton / Long Tons per Month
- Shenzhen Shanghai and any port in China
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Jiangxi, China | Type | Ceramic Plates | |
| Application | Industrial Ceramic | |||
| Model Number | A9634 | Brand Name | ZY |
Product Description
Specifications
1)20 years professional manufacture2)High quality and reasonable price
3)Ontime delivery
4)One-stop service
5)ISO9001:2000
Micro porous ceramic filter media is made up of many bridge arch opening stomatal with uniform distribution and interconnected. When liquid go through this micro porous tube, suspended material, colloidal particles and organic macromolecules are be intercepted in the surface of filter media.
It has some advantages such as corrosion resistance, high temperature tolerance, high mechanical strength, long life and so on. It is widely used in the industry such as oil, chemical, metallurgical, pyroelectric industries, cement, medicine, papermaking and so on. Especially fit for boiler wastewater filtration.
Technical data
| Index | Numerical value | Index | Numerical value |
Capacity(kg/m3) | 1480 | Flexural strength(mpa) | 5.3 | |
Aperture(um) | 10-500 | Antiacid(%) | 98 | |
Void volume(%) | 30-43 | Antialkali(%) | 74-82 | |
Permeable ratio(kg/m2·h) | 15000 | hardness(Mohs) | 7 | |
Breathable ratio(nm3/m2·h) | 1.8-5.0 | Thermal stability(°C) | 200-19 | |
Comp. strength(mPa) | 14 | Water absorption(%) | 23.3 |
Specification of Micro porous ceramic filter media board
Specification | Length | Width | Thickness |
WZC-1 | 250 | 250 | 50 |
WZC-2 | 250 | 250 | 60 |
WZC-3 | 300 | 300 | 65 |
WZC-4 | 500 | 500 | 65 |
Specification of Micro porous ceramic filter media tube
Specification | Outer diameter | Inner diameter | Length | Block head | Thickness | Block width |
WCZ-50-1 | 50 | 30 | 500 | 66 | 15 | 8 |
WCZ-50-2 | 75 | 30 | 700 | 88 | 15 | 8 |
WCZ-100 | 100 | 60 | 700 | 120 | 20 | 10 |
WCZ-120 | 150 | 100 | 1000 | 180 | 25 | 15 |
WCZ-200 | 200 | 140 | 1000 | 230 | 30 | 15 |
