Help CenterRIGHT Series Accurate Straight Linear Guide
Related Products
Specifications
RIGHT Series Accurate Straight Linear Guide1.small maintenance
2.low price
3.high precision
RIGHT Series Accurate Straight Linear Guide
RIT15 ~ 65A type, LA-type, B type, LB-type, R type, LR precision ball-type linear guide, is widely used in CNC machine tools, various cutting machines, woodworking machinery, CNC engraving machines.
1. Compozition: rail, slider, ball, back to the browser, dust cover, Cage, isolation chain.
2. Features:
(1)High efficiency, the driving force of small, energy saving, motor power of small users, thereby reducing costs.
(2) Rail and the slider are very sophisticated. Rail and the slider can realize swaps.
(3). Long service life. Because the rail, the slider quenching high hardness (RC62).
(4). Produced linear rolling guide may realize swaps.
(5).Have glib installed on the slider. Regular gun oil can be used directly to fight grease lubrication can also be replaced by a dedicated pipeline for the oil pipeline connecting joints, the use of automated enforcement oil supply mechanism.
(6). Dust cover with the second dust-proof, dust-proof better.
(7). Isolated chain, thus increasing with the amount of grease, there is no friction between adjacent balls to reduce noise and reduce wear and prolong life. And to reduce the oil gun to fight the number of lubricating grease.
(8). With Cage, the slider from the rail will not get the ball down from the slider on the fall.
(9). Also with a sealing film, screw cap. Users to choose from, adapt to working environment and more dust.
(10). Overweight set type, set type has RIT-LA, RIT-LB, RIT-LC, RIT-LR in four models. Increase in the length of the slider, the effective increase in the number of balls, thus increasing the rated load and stiffness
