High output mobile grain drying machine

  In shaft grain dryers, the temperature of the heat carrier when drying seed grain with a moisture content of up to 25 percent should not exceed 80°C; with a moisture content of over 25 percent the temperature should not exceed 70°C. When drying food grain with a moisture content of up to 25 percent the temperature of the heat carrier should not exceed 110°C, and the temperature for grain with a moisture content of over 25 percent should not exceed 100°C. In rotary dryers, when drying seed grain with a moisture content of up to 25 percent the temperature of the heat carrier should not exceed 145°–165°C, and when drying food grain with a moisture content of over 25 percent the temperature should not exceed 180°-210°C. In a single passage through a shaft grain dryer the moisture content of the grain is decreased by 6–12 percent, and in rotary dryers the decrease is 5–8 percent. The capacity of grain dryers is up to 8 tons per hour. Wood, coal, peat, or liquid fuel may be used as fuel for grain dryers.

For the mobile grain dryer The core function of the mixed flow type three return structure, extend the grain temperature, air pressure, stroke,

speed, using intelligent control.The material in the motion state scattered single particles suspended in the suspended

state, heat exchange, the suspension length of time can be controlled selection.Make full use of the heat exchange effect,

lower the cost of dry.
The material two times for winnowing, sieving, removing impurities.The first floating negative pressure air; the final

screening, cleaning, air cooling.Screening is greater or less than the dry cereal in the debris, and the dried grain for rapid

cooling treatment, achieve the grain and the environment temperature, humidity balance, ensure the normal storage of grain.
Have good mobility.Can take the automobile independent delivery, automobile, tractor and can be moved freely whenever

and wherever possible, equipment for crop drying, realize the true sense of the machine with the object, is very convenient.
Products using electricity, diesel oil as energy supply way, adapt to different geographical and environmental operation of

drying, drying capacity, high work efficiency, low drying cost (0.04 yuan /Kg).
Dried broad in scope, this product is widely used, realizes one machine with multiple functions.Such as wheat, rice, corn,

beans, buckwheat, sunflower seed, rapeseed, fruit and herbs can dry granular.And the special requirements of the seed drying,

maintain the seed germination rate.To achieve the optimization of drying ratio, economize the extremum.

Machine list

1,screw feeding machine:For food feed mechanism, according to the grain moisture content condition control on grain

weight. Motor: Y802-4 0.75kw.
2,Air blower:For blower.Motor: Y132S2-2 7.5kw.
3,Screw feeder:The entrance of the food entering the dryer body.
4,Exhaust fan:For moisture.Motor: Y802-2 1.1kw four.
5,Material heat exchanger:The Noumenon of the Grain drying..
6,Gas collecting chamber:Collection of wet, concentration of emissions.
7,Automatic burner:Drier for heat exchange mechanism, a dryer for drying material heat exchange heat.
8,A grain outlet: collection of grain.
9,Discharging port: collecting slag.
10,Adjustable roller system: the dryer body bearing and rotating mechanism.
11,Fuel tank: Providing the fuel of the drier
12,Electric control cabinet:Dryer appliance operation control.
13,Chassis:Drier base.
14,Gear chain transmission system:Dryer gear.Motor: Y160M-6 7.5kw.
