2012 the Best Ensiling Chaff Cutter
1. Application of Chaff Cutter
Chaffcutter is suitable for cutting all kinds of green grass, tobacco, wheat straw, maize straw, broomcorm straw, sweet potato stem, beanstalk, grain wheat straw and various grass`s rubbing.
2. Chaff Cutter Main Features
1. Steel frame, small size, light weight, mobile convenience.
2. Designed safe Device to stop eating knife accidents, safe and reliable machine.
3. Grass roller shaft coupling is universal coupling, compact structure, flexible operation, convenient disassembly.
4. Diverse choice of motive power. Electric motors, diesel engines, tractors can be complementary; so it can be used in the region lacking of electricity
5. Using high-quality steel blade, made with a special refining process, its super wear-resistant; using of high strength bolts, it is more safe and reliable.
6. Competitive price compared with the same product.
3. Chaff Cutter Working principle
Chaffcutter by motor as a supporting power. Will power transfer to the spindle, the other end of the main shaft gear through the gear box, universal joint, etc will pass the speed to transfer the power of the pressure, and when to grass shengkun materials and processing in pressure between shengkun grass pressure was holding and certain tsao kun speed into Zha cut institutions, the high speed rotating tool cut up by the grass turned out the mouth.
Chaffcutter is a used for processing forage grass, Zha cut green, dry corn straw, straw and the straw returned Zha silage grass machine.hay cutter
Function characteristics: Chaffcutter is suitable for cutting all kinds of green grass, Zha hay, tobacco, wheat straw, YuMiJie, DeGuaYang, etc. Various kinds of forage grass or medicine.hay cutter
4. Chaff Cutter Technical Parameter
|
KY-8.0C |
KY-8.0 |
KY-6.0 |
KY-4.0 |
KY-3.0 |
KY-0.6 |
Dimension (mm) |
4400×2100×4200 |
2700×2000×3000 |
2500×1600×2800 |
1800×1600×2000 |
1600×1000×1800 |
900×700×1000 |
Spindle speed ((r/min) |
|
600 |
650 |
800 |
700 |
900 |
Cuting length (mm) |
15-60 |
10-40(adjustable) |
12-35 |
10-25(adjustable) |
15-25 |
10-30 |
Eject height (mm) |
8-12 |
6-10 |
6-8 |
4-8 |
3-6 |
2-4 |
Production efficiency (t/h) |
dry:5-8 |
dry:1-3 |
dry:≥2.5 |
dry:0.5-1.5 |
dry:0.3-0.8 |
dry:0.1-0.3 |
green:20-30 |
green:6-15 |
green:6-10 |
green:3-5 |
green:1.5-3 |
green:0.3-0.6 |
|
Entire machine weight (kg) |
1800 |
700 |
530 |
385 |
215 |
80 |
With motor (kw) |
22-30 |
15 or 25 horsepower diesel engine |
7.5-11 |
5.5 or 12 horsepower diesel engine |
4 |
1.5-2.2 |
...
