MS High Quality Linear Vibrating Screen
Key words:
Linear Vibrating Screen, Vibrating Screen,Linear Vibrating Sieve,Vibrating Screener,Vibrating Screen,Vibrating Screen,Vibrating Separator,Linear Vibration Sieve Machine
1. What is Vibrating Screen?
Linear Vibrating screen machine is a vibration equipment that using vibration motor as its vibration source . Vibration exciting force enables the material on screen surface to the forward in a straight line parabolic way in order to screening. Linear Vibrating Screen is mainly used for small particles, fine powder screening. In order to get a better screening, 5 is the biggest layers.
2. What is Vibrating Screen Application?
Vibrating Screen is mainly used in abrasives, chemicals, plastics, food, medicine, fertilizer, building materials and other industries.
3. What is Vibrating Screen Features?
Simple structure, easy maintence , low consumption, low noise, good sealing poperty .
4.Vibrating Screen Notice when ordering
a.Customers who are familiar with technical performance and parameters can directly order.
b.Customers who need us to choose the models,please provide the following technical parameters:
Materials' name
Material Ratio
Capacity per hour
Mesh of screen for each layer
Whether the discharge hole have special requirements or not?
5.What is Vibrating ScreenTechnical parameter?
MSZS Linear Vibrating screen | |||||||||
Model |
Layer |
Screen Ssurface Ssize (mm) |
Screen Specification (mesh) |
Particle Size(mm) |
Capcity (t/h) |
Power (KW) |
Dual Amplitude (mm) |
Vibration Time (times/min) |
Sieve Surface Indination(°) |
MSZS-612 |
1-6 |
600*1200 |
2-325 |
≤20 |
≤3 |
0.4*2 |
6-10 |
1460/960 |
0-10 |
MSZS-520 |
1-6 |
500*2000 |
2-325 |
≤20 |
≤5 |
0.4*2 |
6-10 |
1460/960 |
0-10 |
MSZS-525 |
1-6 |
500*2500 |
2-325 |
≤20 |
≤8 |
0.55*2 |
6-10 |
1460/960 |
0-10 |
MSZS-1020 |
1-6 |
1000*2000 |
2-325 |
≤20 |
≤12 |
1.1*2 |
6-10 |
1460/960 |
0-10 |
MSZS-1025 |
1-6 |
1000*2500 |
2-325 |
≤20 |
≤16 |
1.1*2 |
6-10 |
1460/960 |
0-10 |
MSZS-1030 |
1-6 |
1000*3000 |
2-325 |
≤20 |
≤20 |
1.5*2 |
6-10 |
1460/960 |
0-10 |
MSZS-1224 |
1-6 |
1200*2400 |
2-325 |
≤20 |
≤23 |
1.5*2 |
6-10 |
1460/960 |
0-10 |
MSZS-1525 |
1-6 |
1500*2500 |
2-325 |
≤20 |
≤28 |
2.2*2 |
6-10 |
1460/960 |
0-10 |
MSZS-1530 |
1-6 |
1500*3000 |
2-325 |
≤20 |
≤32 |
2.2*2 |
6-10 |
1460/960 |
0-10 |
....
