Product Introduce of 2012 Hot Sale Ceramsite Sand Matt Finish Screen Protector
the screens provide a simple, efficient and economical solution to upgrade a wide rang of material and optimize the subsequent process steps of recovery. This method of screening helps to reduce operating and investment cost and to increase product quality, while allowing rapid and large volume processing.
Our drum screen are constructed of high quality material, designed for high performance, high production rates, lower operating costs and lower maintenance.
This material is then passed on to the downstream process equipment which can be in various forms such as centrifugal Concentrator, spirals, jigs etc.
This drum screen are slope drum installed screens. The drum always rolls and with a sloping angle. When drum start to run, broken materials enter the drum and to be screened alone with the drum rotation, then bigger granularities roll forward along the cylinderm pitch. At the same time, fine granularity roll, and fall down by screening out through different meshes. This drum screen is widely used to support stone, brick, chemical, mining production line.
Matt Finish Screen Protector Main Technical Parameters:
model |
Drum size(m) |
Drum slope |
Deum speed(r/m) |
Mesh size(mm) |
Max feeding size(mm) |
Capacity(m³/h) |
|
Motor power (kw) |
Mesh 2mm |
Mesh 20mm |
|||||||
HJ820 |
Ø0.8×2 |
6º |
32 |
2-20 |
Mesh size×2.5 |
7 |
30 |
3 |
HJ830 |
Ø0.8×3 |
32 |
8 |
50 |
3 |
|||
HJ1030 |
Ø1×3 |
25 |
10 |
60 |
4 |
|||
HJ1040 |
Ø1×4 |
25 |
11 |
80 |
4 |
|||
HJ1230 |
Ø1.2×3 |
20 |
12 |
100 |
5.5 |
|||
HJ1240 |
Ø1.2×4 |
20 |
14 |
120 |
5.5 |
|||
HJ1250 |
Ø1.2×5 |
20 |
15 |
140 |
5.5 |
|||
HJ1530 |
Ø1.5×3 |
17 |
16 |
120 |
5.5 |
|||
HJ1540 |
Ø1.5×4 |
17 |
18 |
150 |
7.5 |
|||
HJ1550 |
Ø1.5×5 |
17 |
20 |
180 |
11 |
|||
HJ1560 |
Ø1.5×6 |
17 |
22 |
200 |
11 |
|||
HJ1850 |
Ø1.8×5 |
14 |
24 |
220 |
15 |
|||
HJ1860 |
Ø1.8×6 |
14 |
26 |
240 |
15 |
....
