Palm fiber EFB dryer machine for biofuel pellets production
Specifications:
1.CE certificated machine.
2.Lower energy consumption.
3.Lower noise.
4.Easy to operate.
Features:
1.It is applicable for drying granular pellet, flake etc
2.The vibrating motor makes materials get rid of moisture through hot air.
3.Specific surface area increase and heat-exchanging efficiency increases.
4.Continuous feeding & charging and high output
5.Easy structure, less mechanical transmission parts, low failure rate and less maintenance.
Technology parameter:
Model |
Power (KW) |
Evaporation Capacity(T/H) |
GHJΦ0.8*6*1 |
4+3 |
0.1-0.2 |
GHJΦ0.8*12*1 |
4+5.5 |
0.2-0.3 |
GHJΦ1.0*6*1 |
4+7.5 |
0.2-0.3 |
GHJΦ1.0*12*1 |
5.5+7.5 |
0.4-0.5 |
GHJΦ1.2*14*1 |
5.5+7.5 |
0.4-0.5 |
GHJΦ1.4*12*1 |
5.5+11+7.5+3 |
0.6-0.8 |
GHJΦ1.4*12*1 |
5.5+15+7.5+4 |
0.8 |
GHJΦ1.6*12*1 |
5.5+18.5+7.5+4 |
0.8-1.0 |
GHJΦ1.6*24*1 |
7.5+22+15+5.5 |
1.0-1.2 |
GHJΦ1.8*12*1 |
7.5+18.5+11+4 |
0.8 |
GHJΦ1.8*12*3 |
11+30+5.5 |
1.0 |
GHJΦ1.8*24*1 |
11+30+4 |
1.0 |
GHJΦ2.0*12*1 |
7.5+22+11 |
1.2 |
GHJΦ2.0*12*3 |
11+45.8+5.5 |
1.5 |
The project case for 3t per hour rotary drum dryer:
1. Customer requirement:
Materials: sawdust. Water content before drying: 50%
Water content after drying:12%
Capacity: 3--3.5t per hour.
II. Working principle of the machine:
The hot temperature flue gas generated by the high temperature stove is fully burned and cleaned by the purifying room.
And it lowers down to 350~400℃ and directly goes into the inner body of the rotary drum dryer. The materials are sent by
the conveying devices into the rotary drum dryer and achieves the fair current drying. The materials are brought up by the
shoveling plate and fell down in a spiral way to go through heat transfer. In order to fully take advantage of the heat, uniform
type lifting board are installed inside of the rotary drum dryer, making the hot wind and materials fully contact and dry.
Then materials move to the another end of the rotary drum dryer and get out.
III. Drying equipment parameter
A. Model: φ1800x22000xδ12mm
With 1 set of speed regulation motor with power of 18.5kw
And 1 set of reducer(model 650, including the uniform type lifting board).
B. Hand operated coal hot air furnace+1.5 level purifying room. Coal burning is 420kg/h. The combustor area is 4.35m2,purifying room is 6.53m2. Heating load is 6.08 million btu.
C. Cyclone specification: 3 sets of φ1000x4000(including the flap valve and 1set of flue-dust retailer).
D. Flue gas induced air fan specification: 4—72 8D 2#
Wind volume: 18134m³/h
Wind pressure: 2005pa y180M—4
Power: 18.5kw/set
E. Air blower specification: 4—72 4A 2#
Wind volume:4506m³/h
Wind pressure:1969pa y132S1—2 power:5.5kw/set
One set of machine frame.
Photos
All our Palm fiber EFB dryer have been approved by CE and SGS vertification.
All our Palm fiber EFB dryer are packaged stretch film inside and wooden case inside.
Shandong Double Crane Machinery Manufacture Co., Ltd.was established in 2009 and is located in Le-ling city, Shandong Province. We are dedicated to the development and production of feed equipment, biomass energy equipment and organic fertilizer equipment. Our company employs 150 skillful personnel. Therefore, we can easily meet your requirements. Thanks to our powerful distribution network, our products are popular with customers in many countries. With rapid development, we have passed CE, SGS and ISO9001 certifications and won many honorary titles. To learn more about what we can do for you, contact us anytime. We look forward to establishing a good and long-term business relationship with you.
1.Technical support online service provided.
2.Technical files service provided
3.On-site training service provided.
4.Spare parts replacement and repair service provided
1. Q: Are you a trading company or a manufacturer?
A: We are a manufacturer, which has almost 10 years of experience in this industry and be able to offer you the best price
2. Q: How can I get to your company?
A: You can get a flight to Jinan Airport. We are just about 1hours away from Jinan Airport.
3. Q: How long is your warranty period?
A: One Year (Calculated from the equipment arrives the customer’s side).
4. Q: Will you send engineers to install the plant?
A: yes, but at an extra cost payable by the customer. Or you can get local contractors to do the commissioning and we send one supervising engineer.
5. Q: Have you sold your products to Europe?
A: Yes, We have designed and installed more than 1000 turnkey pellet lines. Many of our customers are from Europe, including Latvia, France, Greece, Romania, Lithuania, etc.
If you are interested in our Palm fiber EFB dryer, Please let us know the following basic information for making project:
1. What are the materials do yo want to dry?
2. What capacity do you want for an hour?
3. What is the water content before drying?
4. What is the water content after drying?
Thanks.
