Marine Bronze Electric Socket Weld Globe Valve
- 1000 Set / Sets per Month
- Dalian Shanghai Ningbo
- T/T Credit Card
Product Details
Standard or Nonstandard: | Standard | Structure: | Angle | Pressure: | Other, Medium Pressure, 2-10Mpa |
Power: | Manual | Material: | Other, Casting, Cast Iron | Temperature of Media: | Medium Temperature |
Media: | Other, Crude oil, finished oil, Steam, Acidiferous and alkalinous fluid | Port Size: | According to your requirement | Place of Origin: | Chongqing, China |
Model Number: | BMAV0225-5 | Brand Name: | BM | Application: | Other, Maritime, Industry, etc |
Product Description
Marine Bronze Electric Socket Weld Globe Valve
Marine Bronze Electric Socket Weld Globe Valve
Design Features
Straight pattern body design
OS&Y, outside screw and yoke
Tapered, globe, or plug disc
Renewable or welded seat
Bolted bonnet, back seal structure
Impact handwheel for 10" and above
Extended stem design for low temperature
ISO top flange for Bare stem globe valve
Technical Specification
Size: DN 15-DN600
Pressure: PN16-PN100
Material: A105,LF2,F11,F22,F5,F304,F316,F304L,F316L(1/2 -2 )
WCB,LCB,WC6,WC9,C12,C5,CF8,CF8M,CF3,CF3M (2 -24 )
Face to Face Std.: DIN3202,EN1092-1
End Connection Std.: DIN2543-2551
Test Standard: DIN3230
Structure Type: S-Pattern, Oval Pattern, Throttle Pattern
Operated way: Hand wheel, Gear, Pneumatic, Electric Actuator.
Standard:ISO,JIS,DIN,ATSM,CB/T,GB,BG/T,CBM Certificate:CCS,ABS,BV,DNV,GL,LR
The main performance specifications:
DN | L | D2 | H | Flanged Size | Weight(kg) | |||
D | C | n | h | |||||
15 | 55 | 80 | 120 | 80 | 60 | 4 | 12 | 1.98 |
20 | 60 | 100 | 130 | 85 | 65 | 4 | 12 | 2.73 |
25 | 65 | 125 | 145 | 95 | 75 | 4 | 12 | 3.44 |
32 | 80 | 125 | 150 | 115 | 90 | 4 | 15 | 4.77 |
40 | 85 | 140 | 165 | 120 | 95 | 4 | 15 | 5.99 |
50 | 100 | 140 | 200 | 130 | 105 | 4 | 15 | 10.1 |
65 | 115 | 160 | 220 | 155 | 130 | 4 | 15 | 15.6 |
Marine Bronze Electric Socket Weld Globe Valve
Our product Categorie:marine check valve,marine globe valve,marine gate valve ,marine ball valve,marine butterfly valve,marine hose valve, marine check globe valve, marine angle valve,marine screw down check globe valve, marine valve,marine cock, marine pipes,marine fittings,marine accessories.
Other Related Valves:
Valves: Butterfly Valve ; Globe Valve ; Gate Valve ; Check Valve ; Angle Valve
Water Pump: Centrifugal Pump; Vortex Pump ; Jet Pump ; Bilge Pump
Sewage Pump: Submersible Sewage Pump; Sewage Crushing Pump
Fire Pump: Portable Fire Pump; Fixed Fire Pump ; Diesel Emergency Fire Pump
Oil Pump: Gear Oil Pump; Hot Oil Pump; Self-priming centrifugal oil pump
Other Biman Valves
Why Choose BM
A. Excellent service before purchasing
B.M know what the best cost-effective products are. According to clients’ circumstances, we will offer most suitable products for them.
B. Guaranteed quality
Most products which B.M offered are with high quality and also provide warranty to security benefits.
C. Rich experience and Customized Products
B.M has enormous resources of various marine equipment. All of our products are customized.
We can offer products according to your detail equipment and drawings.
FAQ
How to order Valves from Biman?
- Please tell us the Size, Pressure and Quantity and other request you need.
- If you have the certificate requirements, please let me know.
- We'll make quotation for you. After your confirmation, PI will send to you.
- We'll arrange the order for you after receiving your payment
- After the goods finished, we send the goods to you and tell you the tracking number.
