Marine Swing Check Valve DN50

Marine Swing Check Valve DN50 thumbnail-1
Marine Swing Check Valve DN50 photo-1
US$ 125 - 3,690 MOQ: 1 Set
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Check
Pressure:
Other, Medium Pressure, pn16
Contact Supplier Request Quote Chat Now
Chongqing B.M. Import & Export Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
dalian Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Standard or Nonstandard Standard
Structure Check
Pressure Other, Medium Pressure, pn16
Power Manual
Material Other, Casting, Stainless steel
Temperature of Media Normal Temperature
Media Other, fresh water, sea water,air ,crude, oil.
Port Size According to your requirement
Place of Origin Chongqing, China
Model Number BMCV7
Brand Name BM
Application Other, Maritime, Industry, etc

Marine Swing Check Valve DN50

Marine Swing Check Valve DN50

Marine Stainless Steel Swing Check Valve/ Marine Swing Check Valve DN50



1.Features:

1) The check valves supplied are mainly used for preventing the water and steam medium from flowing backward



2) Material:

    a) Valve body and bonnet: ductile iron ASTM-A-536, GGG500-7

    b) Disc: grey iron/ bronze, grey iron or grey iron/ rubber



3) Size: 50 - 400mm/ 2" - 16"



4) Pressure grade

    a) 250 PSI

    b) PN10

    c) PN16



5) Coating

    a) Fusion-bonded epoxy 200-250 microns inside and outside .

    b) Coating as per customers' requirement



2.  Detail Speicifications



Size

DN40 - DN1400

Design Standard

API 609

End flange

EN1092 ,ANSI 125/150# ,DIN2501

Face to face

EN 558-1, BS5155 , ISO 5752

Top flange

ISO 5211





Body

Ductile iron,Stainless steel,WCB

Disc

Ductile iron,CF8,CF8M,C95400,C95500

Stem

SS416,SS420,SS431,SS316

Seat

NBR,EPDM

Suitale medium

Sewage, Sea water, Air, Foodstuff and Oil



Specifications about Marine Stainless Steel Swing Check Valve/Electric Valve



SIZE (DN)

FACE TO FACE

                                 FLANGE (mm)

HEIGHT

mm

 mm

DIA

PCD

BOLT HOLE

 mm

15

60

90

70

4-15

76

20

70

100

75

4-15

93

25

80

125

90

1-19

104

32

100

135

100

4-19

130

40

100

140

105

4-19

130

50

120

155

120

4-19

175

65

140

175

140

4-19

183

80

160

185

150

8-19

215

100

175

210

175

8-19

260



Marine Swing Check Valve DN50

 Marine Stainless Steel Swing Check Valve/ Marine Swing Check Valve DN50

 Marine Swing Check Valve DN50Marine Swing Check Valve DN50



Other Related Valves:



Valves:  Butterfly Valve ; Globe Valve ;  Gate Valve ; Check Valve ; Angle Valve



Water Pump: Centrifugal Pump; Vortex Pump ; Jet Pump ; Bilge Pump



Sewage Pump: Submersible Sewage Pump;  Sewage Crushing Pump



Fire Pump: Portable Fire Pump; Fixed Fire Pump ; Diesel Emergency Fire Pump



Oil Pump: Gear Oil Pump; Hot Oil Pump; Self-priming centrifugal oil pump



 Other Biman Valves

Marine Swing Check Valve DN50

Marine Swing Check Valve DN50 Marine Swing Check Valve DN50 Marine Swing Check Valve DN50

Marine Swing Check Valve DN50

Marine Swing Check Valve DN50



Marine Swing Check Valve DN50

Marine Swing Check Valve DN50



Marine Swing Check Valve DN50



Why Choose BM



A. Excellent service before purchasing

B.M know what the best cost-effective products are. According to clients’ circumstances, we will offer most suitable products for them.



B. Guaranteed quality

Most products which B.M offered are with high quality and also provide warranty to security benefits.



C. Rich experience and Customized Products

B.M has enormous resources of various marine equipment. All of our products are customized.

We can offer products according to your detail equipment and drawings.



FAQ



How to order Valves from Biman?



  1. Please tell us the Size, Pressure and Quantity and other request you need.
  2. If you have the certificate requirements, please let me know.
  3. We'll make quotation for you. After your confirmation, PI will send to you.
  4. We'll arrange the order for you after receiving your payment
  5. After the goods finished, we send the goods to you and tell you the tracking number.
