Marine Cast Steel Manual Operated Flanged Stop Valve / Globe Valve

Marine Cast Steel Manual Operated Stop Valve / Globe Valve

Marine Cast Steel Manual Operated Flanged Stop Valve / Globe Valve

Description:

BIMAN  cast steel globe valve are widely used in the industries of oil, chemical, medicine-made, fertilizer, electrical power, etc. Seat seal surface overlaid with wearing resistant hardened alloy to be matched with disc seal surface; the stem is specially treated to ensure its strength, rigidity, corrosion resistance and abrasion resistance. globe valve is with reliable seal, safe use and easy operation. Valves are available in a complete range of body/bonnet materials and trims,which are widely used for the medium of water, steam, oil product, nitric acid, acetic acid, oxygenation, etc.

Applicable Standard:
Design Standard:  BS 1873, ASME B16.34, DIN3356
Face to Face: ASME B16.10, EN 558, DIN 3202
End Flange:  ASME B16.5, DIN 2501
Buttwelding Ends:  ASME B16.25, DIN3239
Inspection and Test: API 598, DIN3230

Products Range:
Size:  2" ~ 24"(DN50 ~ DN600)
Rating: ANSI 150lb ~ 600lb
Body Materials: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel
Trim: Per API 600
Operation:  Handwheel, Gear, Electric, Pneumatic, Hydraulic
Design Features
Straight pattern body design
OS&Y, outside screw and yoke
Tapered, globe, or plug disc
Bolted bonnet, back seal structure
Impact handwheel for 10" and above
Extended stem design for low temperature
ISO top flange for Bare stem globe valve

Marine Cast Steel Manual Operated Stop Valve / Globe Valve

Other Related Valves:

Valves:  Butterfly Valve ; Globe Valve ;  Gate Valve ; Check Valve ; Angle Valve

Water Pump: Centrifugal Pump; Vortex Pump ; Jet Pump ; Bilge Pump

Sewage Pump: Submersible Sewage Pump;  Sewage Crushing Pump

Fire Pump: Portable Fire Pump; Fixed Fire Pump ; Diesel Emergency Fire Pump

Oil Pump: Gear Oil Pump; Hot Oil Pump; Self-priming centrifugal oil pump

 Other Biman Valves

Why Choose BM

A. Excellent service before purchasing
B.M know what the best cost-effective products are. According to clients’ circumstances, we will offer most suitable products for them.

B. Guaranteed quality
Most products which B.M offered are with high quality and also provide warranty to security benefits.

C. Rich experience and Customized Products
B.M has enormous resources of various marine equipment. All of our products are customized.
We can offer products according to your detail equipment and drawings.

FAQ

How to order Valves from Biman?

1. Please tell us the Size, Pressure and Quantity and other request you need.
2. If you have the certificate requirements, please let me know.
3. We'll make quotation for you. After your confirmation, PI will send to you.
4. We'll arrange the order for you after receiving your payment
5. After the goods finished, we send the goods to you and tell you the tracking number.
