Home > Products > Marine HVAC System > CXL Series Marine All Kinds of Electric Fans
CXL Series Marine All Kinds of Electric Fans
- 4000 Set / Sets per Month
- Shanghai
- T/T
Product Details
Electric Current Type: | Other, AC DC | Place of Origin: | Chongqing, China | Brand Name: | B.M. |
Model Number: | CXL | Voltage: | 380v, 440v | Power: | 0.22-10kw |
Certification: | CE |
Product Description
CXL Series Marine All Kinds of Electric Fans
CXL Series Marine All Kinds of Electric Fans
General
This type is suitable for delivering ordinary air,for sea air containing saltfog,for air containing oil fog and other corrupt air supply or extraition.
It is widely used for the ventilation of kitchens,washrooms,cabins,meeting rooms and public places in marine or nary ships.It is also suitable for some proper places in land chemical and metallurgy departments.
If series fans are equipped with explosion-proof motors,they will be used to deliver gas mixtures or vapour containing combustibles and explosives,and they will operate well in the dangerous areas.
If this type is equipped with AO-H three-phase asynchronous motors for marine use,it will be suitable for the places with 380/220v,50HZor440V,60HZ.(If some have YH series motors,it will meed no 220v.)(three-phase connection)
Features
Own high pressre coefficient(H>1.4)high flow rate(Q>0.5) and high efficiency(Y>65).
Low weight,small size,stable capability and low noise.
It has many property parameter and can be used widely.
Good Intensity,good anticorrosiveness
Strony resistance ayainst swing,vibration and impact.
Working conditions
Medium temperatures:-25℃—55℃
Most relative humidity:95%
Cyclical vacillation 45℃(vacillation cycle 8—12s)
Continuous horizontal tilting 15℃
Continuous vertical tilting 10℃
Vibration:existent
Shock:existentn
Working priciples and struitural forms
CXL series are a new kind of high capable and eneigy-saving fans.It basically adopts AO-H threephare asynchronous motors for marine use.Fans dropellers are made up of many-wing vanes which is fiercely forward.Gas enters vanes' passaye through axes oriention.It produces energy with eccentricity.Gas is compressed and enter the pipes from entrance CXL trpe may be made into a horizontal or vertical structune.The motor is directed conneeted.
The vanes,machine casings and inlets of this series are made of 1cr 18Ni9Ti stainless steel.The vanes are connected by rivet joint,and the machine casing and inlets are weld structune.
There is a fence in the inlet in order to prevent ot-ter things from entering the fans when the inlet pipe is not used.
The vanes must be revised by morement balance.(Adding weigh)
The ventilator can be made for counterclockwise(Left)or clockwise(right) rotation.
Conterclockwese(left) rotation:viewed from the motor side,the rane wheel rotates anticlockwise and indicated as “L”.
Clockwise(right) rotation:viewed from the motor side,the vane wheel rotates clockwise and indicated as“R”.
The outlet position of ventilator,according to the Rotating direction of vane wheel,is made into the fo
Uses and main tenancce
The airflow of CXL,type enters from the axes orientation and is wented from the radial orientation after the vanes unterclockwise(left) or clockwise(right) rotation are both ok.
If collision,friction,high noise and high vibration are met,the fan will be thought not to work normally.It should be checked and then restarted.
Evesything is prevented from impacting the fans,eye winkers and liquid are not allowed into the fans.
Remove the dust on vanes in time in case that it affects the balance and raises noises.
CXL Series Marine All Kinds of Electric Fans
Main Poperty Parameters and out line dimensions
CXL Series Marine All Kinds of Electric Fans
Other Products
marine door: watertight door fireproof door
marine window: rectangular window side scuttle sliding window
marine cover: manhole cover hatch cover
marine ladder: gangway pilot ladder
Why Choose BM
A. Excellent service before purchasing
B.M know what the best cost-effective products are. According to clients’ circumstances, we will offer most suitable products for them.
B. Guaranteed quality
Most products which B.M offered are with high quality and also provide warranty to security benefits.
C. Rich experience and Customized Products
B.M has enormous resources of various marine equipment. All of our products are customized. We can offer products according to your detail equipment and drawings.
FAQ
A. pls provide me the type you prefer
B. If you do not know what kind of type do you need, pls kindly provide me the flow rate, total pressure, static pressure, speed, freq and power. and also the size you need.
