JCZ series marine or navy Extractor Fans

General

JCZ(CZ) seriers marine or navy axial fans (hereafter called the fan) are capable of blowing air, ocean air containing salt vapor, and corrosive air which contains oil vapor and a small quantity of acid steam generated by the natural evaporation of the batteries. They are suitable for cabin air ventilationg and exchanging as well as boiler ventilation on ocean-going vessels, they are also applicable in other places that suit.

The fan is designed and manufactured according to GB/T11864-2008 "Marine Axial Fan" and the current "Ship Building Norms".

Features

The casing can be opened, reverse, good anti-corrosive, strong anti-swing, vibration-proof and shock resistant.

Structure

1. The fan is manufactured with a built-in casing motor strucre. The impeller is directly mounted on the motor shaft.
2. The impeller is made of anti-corrosive cast auminium alloy while the casing is made of weleded common steel.
3. As desired, the casing can either be made into an integral one or an open type along the axial direction, the impeller and the motor are fixed on the movable half of the casing so as to bring convenience for on-the-spot repair and the replacement of its parts.
4. The fan can be matched with AC motor of 38v, 415v, 50Hz or 440v, 60Hz

JCZ Series Marine or Navy Extractor Fans

 Main Poperty Parameters and out line dimensions

 JCZ Series Marine or Navy Extractor Fans

Other Products

marine door: watertight door                    fireproof door

marine window: rectangular window       side scuttle       sliding window

marine cover: manhole cover                    hatch cover

marine ladder: gangway                              pilot ladder

Why Choose BM

 A. Excellent service before purchasing

 B.M know what the best cost-effective products are. According to clients’ circumstances, we will offer most suitable products for them.

B. Guaranteed quality

 Most products which B.M offered are with high quality and also provide warranty to security benefits.

C. Rich experience and Customized Products

B.M has enormous resources of various marine equipment. All of our products are customized. We can offer products according to your detail equipment and drawings.

FAQ

A. pls provide me the type you prefer

B. If you do not know what kind of type do you need, pls kindly provide me the flow rate, total pressure, static pressure, speed, freq and power. and also the size you need.
