CBZ Series Marine or Navy Explosion-proof Wall Mounted Fans

CBZ Series Marine or Navy Explosion-proof Wall Mounted Fans

CBZ Series Marine or Navy Explosion-proof Wall Mounted Fans

General

CBZ series marine or navy explosion-proof axial fans ( thereafter called the explosion-proof fan) are designed and manufactured according to GB/T11864-2008 “Marine explosion-proof axial fans”, GB3836.1-2000 “electrical apparstus for explosive atmosphere”, GB3836.2-2000 “electrical apparstus for explosive atmospheres, and explosion-proof electrical equipment“d”, "Rules for Steel Sea Ship in Class and Building".

This Series fan have been examined and proved up to standard by the Explosion-proof Inspection Authority of the PRC and have got the certificate of inspection. They have also been examined by the Register of shipping of PRC and have got the Certificate

Features

Explosion-proof, state and reliable in operation, well anticorrosive, strongly capable of resisting swing, vibration and shocking.

Structure

There are three structural types: type I (deck type), type II(tube type)and type III (separate cabins type). The construction is non-sparking.

1. Type I explosion-proof fan has an explosion-proof motor installed on the top at the frame and a wire mesh guard with 2/inch, made of stainless steel, surrounding the frame. The fan is vertically fixed on the deck, it can be delivered for air supply or air extraction.
2. Type II explosion-proof fan has no hood, built-in type anticorrosive motor is mounted on the casing by the stalic vane. In can be installed vertically or horizontally, and can also be installed on the deck. It may be used for air supply or air extraction.
3. According to the customer’s special requirement, the fan can be made into III type structure, i.e, the tan and the motor are put in different cabins, with a driving device, a stuffing box and flexible coupling. It is used primarily for exhaust of dangerous compartment.
4. Tacking a front view from the motor, you will see a structure with its impeller turning clockwise

CBZ Series Marine or Navy Explosion-proof Wall Mounted Fans

 Main Poperty Parameters and out line dimensions

CBZ Series Marine or Navy Explosion-proof Wall Mounted Fans

Other Products

marine door: watertight door                    fireproof door

marine window: rectangular window       side scuttle       sliding window

marine cover: manhole cover                    hatch cover

marine ladder: gangway                              pilot ladder

Why Choose BM

 A. Excellent service before purchasing

 B.M know what the best cost-effective products are. According to clients’ circumstances, we will offer most suitable products for them.

B. Guaranteed quality

 Most products which B.M offered are with high quality and also provide warranty to security benefits.

C. Rich experience and Customized Products

 B.M has enormous resources of various marine equipment. All of our products are customized. We can offer products according to your detail equipment and drawings.

FAQ

A. pls provide me the type you prefer

B. If you do not know what kind of type do you need, pls kindly provide me the flow rate, total pressure, static pressure, speed, freq and power. and also the size you need.
