Specifications
Shipboard power cable1.armored power cable
2.Conductor:copper
3.Insulation:XLPE/EPR
4.Sheath:LSOH
0.6/1kv XLPE insulated Shipboard power cable
Application scope
The XLPE shipboard power cable with rated voltage at is 0.6/1kV will be applied to power, lighting and control system on shipboard and off shore platform, and it aslo available to metallurgical industry, chemical works, power plant and mining indudtry ect.
Construction of cable
1.tinner copper conductive cores
2.XLPE insulated
3.wrapping
4.PVC/XLPE/PO inner sheath
tal wire braided
6.PVC/XLPE/PO outer sheath
|
Reference Standard: BS5467,IEC60502 |
Rated Voltage: 600/1000V |
Rated Temperature: 0°C to +90°C |
||
|
Conductor: Class 2 copper conductor |
Insulation: XLPE Compound |
Sheath: PVC Compound |
||
|
Characteristics: High temperature- resistant , Anti-outer big mechanical force | ||||
|
Application: Power and auxiliary control cable use in power networks ,underground ,outdoor | ||||
|
No.of Cores x Normal Cross Sectional Area (mm2 ) |
Normal Thickness of Insulation (mm) |
Normal Thickness of Jacket (mm) |
Over Diameter of Cable (mm) |
Max Conductor Resistance at 20°C ( ≤Ohm/km ) |
2x1.5 |
0.6 |
0.8 |
11.8~12.1 |
13.3 |
2x2.5 |
0.7 |
0.9 |
13.2~13.6 |
7.98 |
2x4.0 |
0.7 |
0.9 |
14.1~14.7 |
4.95 |
2x6.0 |
0.7 |
0.9 |
15.1~15.9 |
3.30 |
2x10 |
0.7 |
0.9 |
17.0~18.0 |
1.91 |
2x16 |
0.7 |
1.0 |
19.2~20.4 |
1.21 |
3x1.5 |
0.6 |
0.8 |
11.8~12.6 |
13.3 |
3x2.5 |
0.7 |
0.9 |
13.3~14.1 |
7.98 |
3x4.0 |
0.7 |
0.9 |
14.5~15.3 |
4.95 |
3x6.0 |
0.7 |
0.9 |
15.3~16.6 |
3.30 |
3x10 |
0.7 |
0.9 |
18.3~19.5 |
1.91 |
3x25 |
0.9 |
1.2 |
24.3~25.5 |
0.78 |
3x35 |
0.9 |
1.2 |
26.8~28.0 |
0.55 |
3x50 |
1.0 |
1.3 |
27.1~28.5 |
0.38 |
4x70 |
1.1 |
1.5 |
36.2~37.7 |
0.28 |
4x95 |
1.1 |
1.5 |
39.9~41.7 |
0.19 |
4x120 |
1.2 |
1.7 |
45.1~47.1 |
0.11 |
4x240 |
1.7 |
2.3 |
61.8~63.0 |
0.03 |
