high shear emulsifier, pipeline homohenizer, emulsifying mixer
General:
A Farfly high shear In line mixer doesn't simply mix. It emulsifies, homogenises, solubilises, suspends, disperses and disintegrates solids. Each mixer, with its precision-engineered rotor/stator workhead, far outperforms conventional mixers,improving quality, product consistency and process efficiency.
Inline high shear mixer
Features:
- Suitable for industrial online continuous production
- Wide viscosity range than in batch high shear mixer
- No batch difference
- High efficiency,low noise
- Special designed three stages rotor/stator for greater shear.
Main technical data:
Capacity
Self-pumping throughputs of 20 to 15,000 litres/hr.
No Bypassing
Product cannot bypass the precision rotor/stator workhead.
Interchangeable Workheads
Single stage rotor/stator configurations workheads as standard. For those applications that require greater shear, interchangeable multistage configurations workheard can be used. there are three stages rotor/stators available.
Materials of Construction
Product contact in SS304 or 316L stainless steel .
Motor Specification
Standard and explosion proof motors (Siemens ,ABB etc) are available as standard.
Inlet and Outlet Connections
All sanitary screw or flange fittings available on request (e.g. ISS, D/N, RJT, SMS, Tri-clamp, etc.).
Sealing
Single or double mechanical shaft seals available as standard.
Cleaning
All Farfly In-Line mixers are designed for cleaning in place (CIP and SIP).
Cooling
Cooling jacket structure as standard
