Coating Filling Machine/Liquid Filling Machine/chemical Filling Machine

Coating Filling Machine/Liquid Filling Machine/chemical Filling Machine photo-1
Coating Filling Machine/Liquid Filling Machine/chemical Filling Machine photo-2
Coating Filling Machine/Liquid Filling Machine/chemical Filling Machine photo-3
Coating Filling Machine/Liquid Filling Machine/chemical Filling Machine photo-4
Coating Filling Machine/Liquid Filling Machine/chemical Filling Machine photo-5
Coating Filling Machine/Liquid Filling Machine/chemical Filling Machine photo-6
US$ 6,000 - 7,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Chemical, Food, Medical, Other, Chemical, Food, Medical, Paint
Packaging Type:
Case
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Chemical, Food, Medical, Other, Chemical, Food, Medical, Paint
Packaging Type Case
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Voltage 220V
Power 0.75
Place of Origin Shanghai, China
Brand Name FARFLY
Model Number FWG/FVG/FQG/FDF
Certification CE/ISO9001
After-sales Service Provided Engineers available to service machinery overseas

Coating filling Machine/Liquid Filling Machine/chemical filling machine

Filling machine, filling machinery, coating filling equipment



A farfly semi-automatic gravimetric filling machine is ideal equipment to fill in paints,inks,oil,detergent as well as some  other liquids.



Features:
·Weight value shows immediately
·Gross/net fililng mode optional
·Automatic/manual operation mode
·Quick / Slow  filling speed
·Emergency stop / break / barrel moves
·Store barrel with automatic material supply control
·Semi-circles slot type hopper convenient for cleaning
·Changeable filling heads
·Filling, cover pressing and capping function combined in one machine
·Explosion proof model is optional

After Sales Service

The above machine which we supply it to you, we can give you one years after sales warranty, we can also send our engineer to you factory to install this equipment and train your staff, but the Buyer should pay the round air ticket cost and arrange the hotel accommodation as well as the meals for Seller’s engineer. We will send some free set of spare parts for you change it.

Payment terms:

30% deposit by T/T before production, 70% balance should be paid by T/T before shipment. but we also accept L/C.

Package:

Standard wooden Case Packing

Shipment terms:

We usually take FOB, but we can also accept EXW,CIF,CNF.

Main technical data:



Weighing scope
≤35kg
Barrel Dimension
≤φ350 x h500mm
Division value
5g
Power source
AC220V/ 50hz
Filling accuracy
≤±1
Air source
0.5MPa
Filling speed
5-12cans/min
Outside Dimension
1500x765x1200(mm)
