Specifications
Sell-propelled agricultural sprayer(Air Blast Sprayer) for pest control in farmland and public areas.ORIOLE air blast sprayer is often used in combination with pickup cars, minivans, or agricultural vehicles to spray chemical herbicides and pesticides. This spraying equipment is widely used in pest control for protection forestry, economic forestry, green forestry and other forestry. Also, it can be used to quickly kill locust and conduct pest control in large open areas.
Configuration
This is a vehicle-mounted, detachable air blast sprayer.
It has complete distribution system, air blasting system, fogging system, air duct steering system and so on. ORIOLE air blast sprayer is directly installed in the compartments of pickup car, minivan or agricultural vehicles. It can be either remote controlled in or outside of the driving cab or manual controlled, and it can spray drugs in the driving process.
Advantages
ORIOLE air blast sprayers have such features as high spraying range and its created fog has good penetrability. They can be used to spray pesticides in the shelter forest, timber forest, greenbelts, as well as other places where there land transportation is convenient. ORIOLE air blast spraying equipment is also ideal for killing locust for corps.
Air Blast Sprayer 3WG400
Dimensions (length × width × height) |
1320×1200×1900(mm) |
|
Size of the tank |
Tank volume(L) |
size(mm) |
470 |
1270×740×710 |
|
1030 |
1460×970×1220(including tank support) |
|
2060 |
1760×1180×1530(including tank support) |
|
Weight of the whole machine |
About 300(Kg) |
|
Air-blasting barrel |
Vertical angle |
-15°~85° |
Horizontal angle |
-60°~60° |
|
Fog drop size |
5 ~50(μm) |
|
Spraying range(case of no wind) |
Vertical spraying range |
Above 20(M) |
Horizontal spraying range |
Above 25(M) |
|
Spraying capacity |
60~400(L/h) (when the air blast sprayer is in operation, the recommended speed of the vehicles that carry the sprayer is 5~10Km/h) |
|
Operating pressure |
3(MPa) |
|
Power of generator |
9.5(KVA) |
|
Fan motor power |
4(Kw) |
|
Fan motor speed |
2800( r/min) |
|
Fan motor voltage |
380(V) |
|
Fan diameter |
Φ500(mm) |
|
Pump motor power |
1.1(Kw) |
|
Pump motor power |
1400 (r/min) |
|
Pump motor voltage |
380(V) |
|
Pumping style |
Triplex plunger pump |
|
Rotation speed of fluid pump |
900(r/min) |
|
