Nitto Denko Nitoflon P.T.F.E No.973ul-s

Nitto Denko Nitoflon P.T.F.E No.973ul-s thumbnail-1
Nitto Denko Nitoflon P.T.F.E No.973ul-s thumbnail-2
Nitto Denko Nitoflon P.T.F.E No.973ul-s thumbnail-3
Nitto Denko Nitoflon P.T.F.E No.973ul-s thumbnail-4
Nitto Denko Nitoflon P.T.F.E No.973ul-s thumbnail-5
Nitto Denko Nitoflon P.T.F.E No.973ul-s thumbnail-6
Nitto Denko Nitoflon P.T.F.E No.973ul-s photo-1
Nitto Denko Nitoflon P.T.F.E No.973ul-s photo-2
Nitto Denko Nitoflon P.T.F.E No.973ul-s photo-3
Nitto Denko Nitoflon P.T.F.E No.973ul-s photo-4
Nitto Denko Nitoflon P.T.F.E No.973ul-s photo-5
Nitto Denko Nitoflon P.T.F.E No.973ul-s photo-6
US$ 7 - 12 MOQ: 1 Roll
Key Specifications
Get Latest Price
Material:
PTFE
Use:
Masking
Adhesive Side:
Single Sided
Contact Supplier Request Quote Chat Now
Shantou Wingtai Packing Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shantou / Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material PTFE
Use Masking
Adhesive Side Single Sided
Adhesive Type Hot Melt, Pressure Sensitive
Design Printing No Printing
Place of Origin Japan
Brand Name Nitto
Model Number 973UL-S(0.13*19*10)

Nitto Denko Nitoflon P.T.F.E No.973ul-s



Product Description





Nitto Denko Nitoflon P.T.F.E No.973ul-s

Color

Beige

Spec.

T0.13mm*W19mm*L10m

Short-term heat resistance

300℃

Continuous heat resistance

-60~260℃

Adhesive Strength

25℃

6.8  N/19mm

100℃

3.2  N/19mm

150℃

2.2  N/19mm

Tensile Strength

240  N/19mm

Unwinding Force

5.9   N/19mm



Nitto Denko Nitoflon P.T.F.E No.973ul-s

  1. Obtain UL510 authentication .
  2. Environmentally friendly products.
  3. Has a good off models and smoothness.
  4. Has good heat retention and dimensional stability.
  5. Nonadhesive surface with electrical characteristics, heat resistance, weather resistance, chemical resistance, water resistance (waterproof), low coefficient of friction, adhesion and other four non-fluorinated ethylene resin possess good properties.
More Specification

Model No.

Spec.

923S

T0.10mm* W38/50mm* L33m

903UL

T0.08mm* W13/15/19/25/38/50/100/250/300/540mm* L10m

903UL

T0.18mm* W18/19/300mm* L10m

903UL

T0.13mm* W19mm* L10m

973UL-S

T0.13mm* W10/13/19/25/38/50/75/100/300/600mm* L10m

973UL

T0.18mm* W19/25/50mm* L10m

975

T0.12mm* W13/19/25/30/38/50/200/300mm* L10m

970-2UL

T0.07mm* W650mm* L10m



Technical Data

Item

No.973UL-S

No.973UL

Thickness (mm)

0.13

0.15

0.18

Tensile strength (N/19mm)

240

590

530

Adhesive strength (N/19mm)

25°C

6.8

9.0

9.7

100°C

3.2

3.9

4.7

150°C

2.2

2.6

3.0

Unwinding force(N/19mm)

5.9

5.9

7.5

Temperature range(℃)

-60~260

Test Method

Compatible with JIS C 2107



Application

• For the heat-resistant masking
• For heat sealing
• For the heat-resistant electrical insulation



Product Picture

 Nitto Denko Nitoflon P.T.F.E No.973ul-sNitto Denko Nitoflon P.T.F.E No.973ul-sNitto Denko Nitoflon P.T.F.E No.973ul-sNitto Denko Nitoflon P.T.F.E No.973ul-s
