PID + Fuzzy Intelligent Temperature Controller Fotek NT-72RE
Model Number: NT-72E
Item Name: PID + Fuzzy Intelligent Temperature Controller
Fixed Method |
Panel Type |
Rall Type |
||||||
Model |
NT-10 |
NT-48 |
NT-20 |
NT-21 |
NT-72E |
NT-96E |
NT-22 |
NT-32 |
|
Outline (U t:mm) |
24*48* 100 |
48*48*72 |
48*96*60 |
96*48*60 |
72*72*60 |
96*96*60 |
22.6*75* 100 |
32*75* 65 |
Alarm Output |
Single Alarm |
Two Alarm |
Single Alarm |
Two Alarm |
||||
Power Supply |
90~265 VAC / 50/60 Hz or 24VDC / AC (Optioned) |
|||||||
Power Consumption |
5VA max. Or 100mA max (24VDC / AC) |
|||||||
Input Method |
PT / K / J / R / S / T / B / E / N / L (Selectable) or 4~mA or 0~10 VDC (Optioned) |
|||||||
Control Method |
Fuzzy + PID or ON / OFF selectable |
|||||||
Control output |
Relay or SSR or 4~20 mA(Optioned) |
|||||||
Alarm Output |
Relay 1a (3A / 250VAC SPDT) |
|||||||
Display Range |
-999~9999 |
|||||||
Accuracy of display |
+/- (0.1% OF F.S. +1 DIGIT) |
|||||||
Setting Range |
-999~9999 |
|||||||
Memory Method |
EEPROM |
|||||||
Insulation Resistance |
Over 50MΩ / 500VDC |
|||||||
Dielectric Strength |
OVER 2.5 KV / 1 MINUTE |
|||||||
Operating Circum |
-25℃~80℃; 35%~85% RH |
|||||||
EMC Standard |
ESD: 8KV Air Discharge (Level 3) / EN-61000-4-2 RF Interference: 10V / M / ENV-50140 Burst Test: 2KV / EN61000-4-4 |
|||||||
Please Click the Headline. View More...
|
|
|
