Help CenterProfessional Cold Storage Room,Cooling Room for Fish and Meat
Related Products
The complete set of fish cold room includes 4 main parts
1. Make cold storage room panels 2. Air cooler
3. Condensing unit 4. Accessories
Fish Cold room are widely used
in food process factory, dairy factory, pharmaceutical factory, chemical factory, fruit and vegetable warehouse, egg storage, hotel, supermarket, hospital, blood bank, troops and laboratory.
Our fish cold room has the following features
1. Nice appearance: The insulation panel and framework are available in dozens of colors which are to be elected in satisfactory harmony with various styles of buildings...
2. Insulation: Polyurethane or polystyrene with low thermal conductivity and high strength is utilized, achieving good insulation performance.
3. Short construction period
4. Fast installation
5. Hygienic conditions of food inside cold stores are up to the standards.
6. Durable building structure, super quality material
7. Temperature: -20°C~-30°C or -10°C~-18°C or 8°C~-5°C
8. Size: Customization
Cold room panels has such features:
1)good fire prevention performance and not melting when burning
2) wide temperature application range, small contractility even in low temp environment and non fragile.
3) nontoxic and inodorous, in accord with the state environmental protection requirements
Condensing unit
This series products feature box type structure with hermetic and semi-hermetic compressor, that is compact and pleasant looking, applicable to cold display cases, cold storage rooms, ice producers etc.
We have 3 compressor brand types for your choice: German bitzer, American Copeland and French Maneurop.
Air cooler
Features of air cooler are as following:
1 This kind of air-cooler is specially designed for preservation, refrigeration and cold storages
2) The shell is made of quality steel plate; Sprayed plastic surface is anti-corrosive, and its appearance is handsome
3) Coiled pipes are mechanical expanding tubes in staggered arrangement; Therefore, copper tubes and aluminum sheets are combined closely.
4) Long-distance air supply ducts can be used
If you enquiry cold room, pls kindly confirm the following information:
1. What is your cold storage room used for
2. What is your required room temperature
3. What is the cold storage room dimension or how much food or other
Products will be put inside
Pls kinldy confirm the above information and we will reply you in 2 days.
| Room temp | Panel thickness(mm) |
| 5~10°C | 60 |
| -5~5°C | 80 |
| -12~-5°C | 100 |
| -20~-12°C | 120 |
| -30~-20°C | 150 |
| -40~-30°C | 200 |
Our main components of condensing unit are as follows:
| Item | Name of Components | Brand Name | Country | |
| 1 | Compressor |
Copeland Bitzer Maneupop |
American German French |
|
| 2 | Cooling fan | Kewely |
China |
|
| 3 | Condenser | Kewely | ||
| 4 | Expansion valve | DANFOSS | Denmark | |
| 5 | Solenoid valve | CASTEL | Italy | |
| 6 | Electrical components | LG (LS) | South Korea | |
| 7 | Refrigerant Receiver | Onda | China | |
| 8 | Filter drier | Danfoss | Denmark | |
| 9 | High and low pressure relay | Danfoss | Denmark | |
| 10 | Pressure meter | Refco | Switzerland | |
