BIOMASS GENERATOR POWER PROJECT 20KW-500KW
US$ 13,500 - 150,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Chongqing, China
Brand Name:
CAMDA
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shenzhen China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
NATURAL GAS GENERATOR POWER PLANT 20KW-500KWUS$ 13,500 - 155,000MOQ: 1 Set -
Biogas Generating Project in SwedenNegotiableMOQ: 1 Set
-
Biogas Generating Project in NigeriaNegotiableMOQ: 1 Set
-
Biogas Generating Project in KenyaNegotiableMOQ: 1 Set
-
Biogas Power Plant in MalaysiaNegotiableMOQ: 1 Set
Condition
New
Place of Origin
Chongqing, China
Brand Name
CAMDA
Model Number
KDGH-G
Voltage
220V/380V,230V/400V(Can adjust)
Power(W)
20KW(25KVA)-500KW(625KVA)
Weight
2500KGS
Dimension(L*W*H)
3000*2200*1800MM
Certification
CE, ISO,SGS
Warranty
1 Year or 2000 Running Hours
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Biomass generator power project use animal waste, agriculture corps and all of organic materials for anarobic digesting.BIOMASS GENERATOR POWER PROJECT 20KW-500KW
Biogas power plant/ Cogeneration plant/Gas power plant
Genset working condition:
Acceptable working conditions:
Ambient temperature : 0°C~+40°C
(antifreeze, oil and water heater needed for below 0°C)
Relative humidity:lower 90%(20°C)
Altitude:lower than 1000m
Normal working conditions:
Genset can run at rated power on the conditions:
Atmospheric Pressure: 100kPa, Ambient Temp: 20°C, Relative Humidity: 30%
Applied gas:
Gas, natural gas,biomass,methane gas,CNG
| Camda H Series Gas Generator Set Parameters | ||||||||
| Model Item | KDGH30-G | KDGH50-G | KDGH80-G | KDGH120-G | KDGH200-G | KDGH300-G | KDGH500-G | |
| Rated power | KW | 30 | 50 | 80 | 120 | 200 | 300 | 500 |
| KVA | 37.5 | 62 | 100 | 150 | 250 | 375 | 625 | |
| Rated Voltage (V) | 400 | 400 | 400 | 400 | 400 | 400 | 400 | |
| Frequency (Hz) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | |
| Rated Current (A) | 54.1 | 90.2 | 144.3 | 216.5 | 360.9 | 541.3 | 902.1 | |
| Voltage Stabilized Regulation | ≤±1.5% | ≤±1.5% | ≤±1.5% | ≤±1.5% | ≤±1.5% | ≤±1.5% | ≤±1.5% | |
| Voltage Instantaneous Regulation | ≤±20% | ≤±20% | ≤±20% | ≤±20% | ≤±20% | ≤±20% | ≤±20% | |
| Voltage Recovery Time (S) | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 | |
| Voltage Fluctuation Ratio | ≤1% | ≤1% | ≤1% | ≤1% | ≤1% | ≤1% | ≤1% | |
| Frequency Fluctuation Ratio | ≤1% | ≤1% | ≤1% | ≤1% | ≤1% | ≤1% | ≤1% | |
| Generator Insulation Class | H | H | H | H | H | H | H | |
| Noise Level (Db) | ≤95 | ≤95 | ≤98 | ≤98 | ≤100 | ≤100 | ≤102 | |
| Engine Model | HG4B | HG6B | HGN14 | HGN14 | HGNT14 | HGK19 | HGK38 | |
| Aspration | Natural | Natural | Natural | Natural | Turbocharged | Turbocharged | Turbocharged | |
| Inline | V type | |||||||
| Four stroke, electronic-control spark plug ignition, water-cooling, premix proper ratio of air and gas before combustion | ||||||||
| Cooling Mode | Radiator fan cooling for closed-type cooling mode, or heat exchanger water cooling for cogeneration unit | |||||||
| Cylinders | 4 | 6 | 6 | 6 | 6 | 6 | 12 | |
| Bore X Stroke (mm) | 102*120 | 102*120 | 140*152 | 140*152 | 140*152 | 159*159 | 159*159 | |
| Displacement (L) | 3.92 | 5.88 | 14 | 14 | 14 | 18.9 | 37.8 | |
| Compression Ratio | 11.5:1 | 11.5:1 | 11 : 1 | 11 : 1 | 11 : 1 | 11 : 1 | 11 : 1 | |
| Rated Power (Kw) | 36 | 56 | 145 | 145 | 230 | 336 | 570 | |
| Rated Speed (r/Min) | 1500 | |||||||
| Fuel | Natural Gas / Biogas | |||||||
| Gas Consumption (MJ/Kw·h) | 12 | 11.9 | 11.8 | 11.8 | 11.2 | 10.9 | 10.5 | |
| Idling Speed (r/Min) | 700 | |||||||
| Oil Recommended | API service grade CD or higher SAE 15W-40 CF4 | |||||||
| Oil Consumption | ≤1.0g/kW.h | ≤1.0g/kW.h | ≤1.0g/kW.h | ≤1.0g/kW.h | ≤1.0g/kW.h | ≤1.0g/kW.h | ≤0.5g/kW.h | |
| Exhaust Temperature | ≤ 680°C | ≤ 680°C | ≤ 650°C | ≤ 650°C | ≤ 600°C | ≤ 600°C | ≤ 550°C | |
| Net Weight (Kg) | 900 | 1100 | 2225 | 2525 | 2525 | 3380 | 6080 | |
| Dimension (Mm) | 1850*750 *1500 | 2250*820 *1500 | 3000*1100 *1800 | 3150*1100 *1800 | 3150*1100 *1800 | 3470*1230 *2300 | 4400*2010 *2480 | |
