high efficiency Linear Vibrating Screen

Specifications

Linear vibrating screenSZF Series Linear screen is used as electrical vibration exciter source materials in the online screen.

1.Introduction of Linear vibrating screen

SZF Series Linear screen is used as electrical vibration exciter source material in the online screen Upon the impact, while forward exercise, a reasonable match of the day mesh screening purposes. Materials from the feeder uniform access to the screen-mouth feed through the generation of multi-screen products and the failure of the screen, under the screen of the exports were discharged from their respective. Pipeline can be used to automate operations.



2.Feature of Linear Vibrating Screen

With low energy consumption, high efficiency, simple structure, easy maintenance, all closed structure and characteristics of dust pollution.



3.Application of Linear Vibrating Screen

Widely used in plastics, abrasives, chemicals, pharmaceuticals, building materials, food, food, carbon, fertilizer industries.



4.Technical parameter of Linear Vibrating Screen

Model	SZF520	SZF525	SZF530	SZF1020	SZF1025	SZF1030	SZF1225
Nominal size	500×2000	500×2500	500×3000	1000×2000	1000×2500	1000×3000	1200×2500
Granularity	0.074-60	0.074-60	0.074-60	0.074-60	0.074-60	0.074-60	0.074-60
The vibration	960	960	960	960	960	960	960
Screen lofts	1°-7°	1°-7°	1°-7°	1°-7°	1°-7°	1°-7°	1°-7°
Amplitude	1-4.5	1-4.5	1-4.5	1-4.5	1-4.5	1-4.5	1-4.5
Layers	1-6	1-6	1-6	1-6	1-6	1-6	1-6
Power	2(0.37-0.75)	2(0.37-0.75)	2(0.37-0.75)	2(0.37-1.1)	2(1.1-1.5)	2(0.75-1.5)	2(0.75-1.5)
