Help CenterHigh Performance Sand Mill
Related Products
-
Sand Making Machine of High Performance and Cavity CrushingUS$ 999 - 99,999MOQ: 1 Set -
PCL Sand Making MachineUS$ 6,600 - 50,000MOQ: 1 Set
-
Sand Making Plant / Sand Making ProjectNegotiableMOQ: 1 Set
-
Fine CrusherUS$ 1 - 99,999MOQ: 1 Set
-
Fine Crusher of High PerformanceUS$ 1 - 99,999MOQ: 1 Set
Specifications
sand making machine features:-Reasonable structurer and design
-Excellent all-around service
-Special dust device
sand maker,sand making machine
Working Principle of Sand Making Machine:
1.Center Feeding:
Raw material falls down into feed hopper, then enter into impellor through central entrance hole. It is accelarated in high-speed impellor, then is thrown out at speed of 60-75m/s. When it hits impact plate, it is crushed. Final products come downwards though outlet.
2. Ring Feeding:
Raw material falls down into feed hopper, then through ring, it is divided into two divisions by material-deviding plate. One enters into impellor through the center of material-deviding plate. The other falls down from outside of material-deviding plate. Material, which is thrown out by impellor at speed of 60-75m/s, hits material coming down from outside of material-deviding plate. In this way, material is crushed.
type |
Rotor Diameter(mm) |
Rotor lengh(mm) |
Revolution of Rotor (r/min) |
Input size(mm) |
Output size(mm) |
cobble(t/h) |
Lime stone(t/h) |
Power(kw) |
PFC-0808 |
800 |
800 |
960 |
below100 |
below5 |
30-45 |
40-65 |
55 |
PFC-1010 |
1000 |
1000 |
887 |
below150 |
below5 |
35-55 |
50-100 |
75 |
PFC-1212 |
1200 |
1200 |
760 |
below150 |
below5 |
40-100 |
60-120 |
132 |
PFC-1414 |
1400 |
1400 |
676 |
below200 |
below5 |
60-120 |
70-150 |
160 |
