Specifications
PCB Metal Recycling Machine1.Professional circuit board recycling
2.High recycling rate
3.Up to 99% purity
4.12 months w
PCB recycling machine/Circuit Board Recycling Machine
This PCB recycling machine is applicable to recycle mother boards of PC, waste circuit
boards from mouse, telephone and TV, trimming of copper clad laminate (CCL) etc.
Features of this PCB recycling machine:
(1) High recycling efficiency
(2) Good at solving problem of fibrous dust from kinds of circuit boards when pulverizing
(3) Eco-friendly
(4) Easy to operate and replace spare parts
Brief Introduction of PCB Recycling Machine
The series is the first complete set of recycling equipment of waste and old printed circuit board in China. It has gotten the technical patent (patentno: ZL00206557.6).The equipment adopts advanced, innovative physical recycling technique. It pulverizes and recycles waste and old printed circuit board .The purity of recycling metal can reach to 97%.The highest amount of metal, copper, accounts more than 17%.The gold and sliver is separated in physical way. Other epoxy resin, Bakelite and fiberglass are recycled to be used as floor brick, decorating material, insulating material, furniture, etc.
Widely Application of PCB Recycling Machine/Circuit Board Recycling Machine
This PCB recycling machine is applicable to recycle mother boards of PC, waste circuit
boards from mouse, telephone and TV, trimming of copper clad laminate (CCL) etc.
Parameter of the machine
model |
Power(KW) |
Weight(t) |
package |
Capacity(t/d) |
Equipment for recycling waste and old circuit board |
49 |
6.5 |
One container |
3-5 |
The whole set including:
Primary crusher –main grinder—classifier—Rotary screen——cyclone separating device—powder collector---dust catcher—other devices
Equipment Specifications
Main Motor Model: 1000
Rotary vibrating screen:Φ800
Classifier: 350
Primary crusher:300
Fineness of machining fore and after
Input size: below 400 mm
Output size: 20-100 mesh
primary crusher
1) Delivery: within 10 days after receiving the earnest money.
2) Period of validity: 1Month
3) HS CODE 84742090.00
4) Specification: in the table above.
5) Warranty: 100% brand new when leaving the factory. The seller guarantee quality of the machines for a period of one year from the date of trial run finish, but not to exceed 18 months from date on which machine leaves the factory. If any parts (excluding wearing parts) are found defective in quality in the first year, the seller should replace free-of-cost. After one year, parts can be replaced on favorable payment basis.
6) 2 people with 60 square meters.
No wastewater, we have dust collector for this machine.
