Professional rebar cutting machine
rebar cutting machine
Rebar cutting machine fit to cut a lot of steels used in various concrete structures of construction projects, such as common carbon steel, hot and cold-rolled round steel, deformed steel bar, as well as flat steel, square steel and angle steel (special cutting tool is needed). It is capable of cutting the steels with a diameter of 6-40mm, and has a lot of advantages such as perfect lubricating performance, low power waste, simple operation process, high efficiency and convenient moving property.
No. |
Item |
Model |
||||
GQ40B |
GQ40A |
GQ50 |
RC-25 |
CYQ50A |
||
1 |
Φ4-40mm |
Φ4-40mm |
Φ4-50mm |
Φ4-32mm |
Φ4-50mm |
|
2 |
Φ4-32mm |
Φ4-32mm |
Φ4-42mm |
Φ4-28mm |
Φ4-42mm |
|
4 |
50mm * 18mm |
50mm * 18mm |
50mm * 18mm |
* |
50mm * 18mm |
|
|
speed |
28times/min |
28times/min |
28times/min |
15times/min |
28times/min |
6 |
power supply |
3KW |
3KW |
4KW |
1.3KW |
7.7KW |
7 |
control mode |
hand clutch / foot pedal |
hand clutch / foot pedal |
hand clutch / foot pedal |
hand clutch / foot pedal |
foot pedal |
8 |
voltage |
380V/50HZ/3phase |
380V/50HZ/3phase |
380V/50HZ/3phase |
380V/50HZ/3phase |
* |
9 |
whole weight |
608kg |
430kg |
380kg |
32kg |
900kg |
Q : What's the main advantage of rebar cutting machine ?
A:1. Enhanced machine rack, small volume, compact structure, solid and reliable.
2. Good lubricating property, adopt enclosed gear box, use the gear splashing to realize lubrication. It can work constantly for two months after adding 8kg gear oil.
3. Little power consumption because of the lubrication improvement. The gear section adopts rolling bearing, less resistance . Compared with same type cutting machine, load power can be reduced by one third.
4. Using high rigid cutting head, connecting rod and high speed national standard motor, guarantees more stable quality and longer service life.
Q : What's the main Usage ?
A : Cut all steel material, like ordinary carbon steel, cold & hot round steel, screwed thread steel, flat/angle/square/scrap/deformed steel
Q: What's the mainly applied ?
A: Rebar cutting machine mainly applied to buildings, Bridges, tunnels, power stations
large-scale water conservancy projects for steel fixed length cut off
Main Spare Parts
Wooden case
Engineers available to service machinery overseas
We can provide free training to end-users
Warranty: 1 year
GongYi HengYuan Industry Co., Ltd is located in GongYi, ZhengZhou, HeNan Province—China
