Help CenterCharcoal Ball Briquettes Production Line Egg Shape
Related Products
-
High Efficiency Coal Powder Ball Machine Capacity:3ton-10ton per HourUS$ 2,400 - 3,200MOQ: 1 Set -
Low Cost Pillow Shape Coal Powder Ball PressUS$ 2,400 - 3,200MOQ: 1 Set
-
Oval Coal Ball Extruders Top QualityUS$ 2,400 - 3,200MOQ: 1 Set
-
Two Rollers Coal Ball Bruquetting PressUS$ 2,400 - 3,200MOQ: 1 Set
-
Coal Powder Forming Machine 0086 15890664277US$ 2,400 - 3,200MOQ: 1 Set
Specifications
carbonization charcoalcrushing--mixing with binder---charcoal ball briquettes machine
offer whole line solution
ISO
The working proccess is as following when the raw materials is the wood chips, coconut shell or others
The working process could be carbonize the raw materials into charcoal---- 3m belt conveyor----charcoal crusher---rotary mixer for binder--- with charcoal powder--5mbelt conveyor---charcoal ball briquettes machine ---
step 1 charcoal crusher
The Vertical Complex Crusher is a new type of rough grinding and fine crushing product combined the domestic and foreign crushing technologies together, developed and designed by our team of highly qualified engineers on main technical parameter.
special features
high and cubic crushing ration
low energy consumption
steady running
smart structure and easy operation and maintain
Model |
Max-Input Size (mm) |
Output Size (mm) |
Capacity (TPH) |
Power (kw) |
Overall Dimension (mm) |
Weight (kg) |
500 |
≤20 |
≤3 |
1.5-3 |
5.5 |
1050*750*950 |
300 |
600 |
≤20 |
≤3 |
3-6 |
15 |
1150×750×1200 |
1100 |
700 |
≤20 |
≤3 |
8-10 |
22 |
1650×900×1300 |
1900 |
Second step
We use the mixer with binder, we had better to use the rotary mixer when raw materials is the charcoal type
This machine is used to mix the grinded charcoal dust (charcoal powder) with water and binder etc. It can flip on the side to drop the charcoal automatically after mixing without taken by hand.
Model |
Power (kw) |
Capacity (kg/h) |
Weight (kg) |
Dimensions, mm |
Roller –mixer |
5.5KW |
1-3 |
650 |
1100*1002*1000 |
1.9 meter |
7.5kw |
5-8 |
450 |
1900*450*1000 |
2.5meter |
11KW |
10-15 |
750 |
2500*450*1000 |
Third step
We make the charcoal briquettes by charcoal ball briquettes machine
This series of coal briquette press machines can be used to make coal briquettes of different shapes. The raw material comes from small size waste charcoal broken in storage or while transportation, or comes from charcoal chunk after biomass burned. With this machine, the waste charcoal chunk can be made into charcoal briquettes or charcoal stick and recycled for barbecue, room heating etc.
The main technical data is as following
Model |
290 |
360 |
430 |
500 |
650 |
800 |
1000 |
Roller Dia ( mm) |
290 |
360 |
430 |
500 |
650 |
800 |
1000 |
Motor Power(KW |
5.5 |
7.5 |
15 |
18 |
25 |
30 |
45 |
Capacity (t/h) |
1-3 |
4-6 |
6-8 |
8-10 |
10-15 |
15-20 |
22-30 |
Welcome to contact me by the following information
