Brief instruction of terrazzo floor brick making machine
terrazzo floor brick making machine independently developed color terrazzo floor tile
production line,using the slurry high speed filter principle,wear-resistant precision
mold,through mechanical mixing,to brick press high pressure molding.
High production efficiency,high degree of automation,process control.Compared with the dry
principle forming has a large,high density,strength ,permeability rate is low,dimensions.Indeed,and many other advantages.
Imported microcomputer PLC control procedures,is a set of mechanical,hydraulic,pneumatic,
automation and control computer integration of advanced equipment.
The working process of terrazzo floor brick making machine
Bucket elevator---- Blender---- Doser----terrazzo floor tile making machine
Working flow of terrazzo floor brick making machine
1. Prepare the raw materials, then put them into the bucket elevator in proportion.
2. Mix them together in the grinding mixer, and add some water at the same time.
3. Start the constant feeder, every time constant materials will come down to the bellow mold.
4. The host machine will press the raw materials, then a finished terrazzo floor tile will be ok.
5. Take out the finished tile, and put it on the rack tile frame or put them on the floor.
6. Maintain the finished tiles regularly
terrazzo floor brick making machine
Model |
YR5060 |
YR4050 |
YR3040 |
Production size |
600*600mm 500*500mm |
500*500mm 400*400mm |
400*400mm 300*300mm |
Forming pressure |
350t |
250t |
128t |
Power |
15kw |
7.5kw |
5.5kw |
Capacity |
3-5pieces/min |
5-6pieces/min |
7-8pieces/min |
Overall dimension |
3300*1600*2700mm |
2700*1500*2500mm |
2700*1500*2500mm |
Weight |
7.8t |
6.8t |
5t |
Bucket elevator:
Power |
3kw |
weight |
0.4t |
Dimension |
5900*3000*1100mm |
Blender
Power |
5.5kw |
Weight |
0.6t |
Dimension |
1500*1300mm |
Doser
Power |
1.5kw |
Weight |
0.6t |
Dimension |
1500*1300*2100mm |
mold of terrazzo floor brick making machine
different mold for you choose ,we could design the mold as you request,or customer-design the mold according your budget
Performance of terrazzo floor brick making machine
1 the quality of product thickness by adjusting the quantitative cup can be adjusted
2 high degree of automatic,simple operation,equipment operation only 2-3 people
3 the production cost is low,the labor intensity is small ,low energy consumption,no pollution
4 product size accuracy,high pressure,high strength,various patterns,lines clear
Advantages of terrazzo floor brick making machine
1 with low cost ,low consumption,and high efficiency
2 with low labor intensity,high automation,easy to operate.
3 product size;3300*1600*2700mm 2700*1500*2500mm 2700*1500*2500mm
Different capacity,and more choose for you
4 easy to find raw material is cement,stone dust gravel and water,this is very cheap
5 the production line just need 2-3 persons to operate the entire production line
our serive for terrazzo floor brick making machine
1 pre-sale service;design and produce machines according your budget and workplace,
to help you learn more details information about the production line working process
2 on-sale service;we could provide the train how to operate the production,and how to
maintain all machines,
support examine goods before pay balance payment
3 after-sale service;guarantee period for machines is one year without wearing parts
Provide professional engineer to guide with device installation,train
welcome contact me by follow information
