Competitive Price Oak Wood Charcoal Briquette Making Machine
- 500 Set / Sets per Month
- Shanghai Qingdao Ningbo Guangzhou Lianyungang
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | Lantian |
Model Number: | LT260 | Voltage: | 220V 380V 450V | Power(W): | 11kw |
Weight: | 4.5T | Dimension(L*W*H): | 2.2*1.6*2.2 | Certification: | CE ISO |
Warranty: | 12 Months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Characteristics
Oak Wood Charcoal Briquette Making Machine
1.Low price,High quality.
2.High briquetting pressure
3.Automatic operate
Competitive Price Oak Wood Charcoal Briquette Making Machine
♠Sample show
Shape: Oak Wood Charcoal Briquette Making Machine can make round, cylindrical, square, rectangle, polygonal, hexagonal, etc. Or you can have your own ideal shape.
Size: the final size is according to the shape and the machine mould, also you can decide it under certain range.
Characteristics: the product is processed into high density, combustion time is long, non-toxic, smoke-free, etc.
♠Other raw material
(1) Energy conservation and environmental protection,no waste gas,clean and health.
(2) Quantity of heat of final product is 500-1000Kcal higher than raw material.
(3) Can replace firewood and liquefaction gas, with less investment.
(4) Small cubage and easy for transport.
(5) Adopt high-speed, high-frequecy stamping technique, ensure the stability of the molding.
♠Show the machine
Oak Wood Charcoal Briquette Making Machine has simple structure, including body, motor, feeding, punching, and transportation.
Body : Consist of platen, engine base, forming the skeleton entity.
Driving parts: Consists of motor, belt pulley, gear, transmission shaft, etc. The motor make the gear shaft rotating through belt pulley, and through two gears pass to axis, and then by a pair of bevel gear and the axis of rotation to drive the dial, and then pass to the four panel movement.
Feeding part: Is composed of spindle, hopper, mixer, through the rotation of the spindle, automatic feeding and stir.
Punching parts:Intermittent work, feeding, stamping, molding.
Transmission parts: By the transmission rack, pulley, and other components of the conveyor belt, conveyor frame can be adjusted by the adjusting screw on the elastic.
Oak Wood Charcoal Briquette Making Machine also can use for pressing the coal ,ferrum pulveratum,aluminum powder,carbon powder,slag,gypsum,sludge,activated charcoal such as all kinds of powder.Widely used in powder plant,metallurgical,chemical,energy,carriage,supply heating and other industries.Energy conservation and environmental protection and transport easily,to improve the utilization of waste and also has good economic and social effect.
In order to meet the different needs of different customers,our factory has designed different types of mold and all of the molds are produced by ourselves according to the customer's requirements,meanwhile the mold materials are use durable.
Oak Wood Charcoal Briquette Making Machine's mold is easy to repair and install. Change mold can be different shapes, we can customize the mold as your requirements, If the mold be weared. we can provide the mold with low price and high quality.
♠Main Parameter
Model | Motor Poeder (KW) | Capacity (PCS/Min) | Werght (T) | Oversize (M) | Size of briquette(MM) | |
Circle | Square | |||||
LT140 | 7.5 | 50 | 1.8 | 1.3*1.4*1.8 | Belowφ140 | Belowφ100*100 |
LT160 | 7.5 | 50 | 2.2 | 1.5*1.6*1.9 | Belowφ160 | Belowφ120*120 |
LT180 | 7.5 | 40 | 2.5 | 1.6*1.5*2.1 | Belowφ180 | Belowφ150*150 |
LT220 | 11 | 22-26 | 3.8 | 1.9*1.6*2.1 | Belowφ220 | Belowφ200*200 |
LT260 | 11 | 27 | 4.5 | 2.2*1.6*2.2 | Belowφ260 | Belowφ220*220 |
♠Mold show
Look at the major manufacturers processing equipment,Professional Oak Wood Charcoal Briquette Making Machine vendors would have to have spline broaching machine(Our factory 14 years ago to invest 1.8 million imported German spline broaching machine).Spline not only cooperate closely in the structure, and small equipment noise, smooth operation, positioning precision, convenient maintenance, not easy dislocation between components.
♠Packaging Details
(1) Single Oak Wood Charcoal Briquette Making Machine by wooden case packing by LCL,whole line machine by container or as client's demand.
(2) wood case for charcoal making machine,One product line need 1x40GP
(3) standard sea shipping plywood case or as clients' demand
(4) Single machine packed with fumigation free wooden case.
(5) Multiple machines loaded in 20GP,40GP or 40HQ container.
Before the sales
1. According to the customer's requirement, provide the most suitable project design, process design and the purchase program.
2. We will guide customers to choose the best and economical machine, recover investment within short time and site inspection.
In the sales
1. Accompany you to check the working conditions of the Oak Wood Charcoal Briquette Making Machine.
2. Lead to visit all of our machines.
3. Dozens of arrange delivery after received customer's advance payment.
After-sales
1. Engineers available to service machinery overseas to help you install, debug, build plant at the same time provide adhesive technology.
2. Guarantee the quality of equipment, when the equipment in the production have any questions we will timely solution for you.
We have also got the CE, ISO, SGS and other several patents.Our machines are sold at home and abroad praised by customers highly for exampe Indonesia, Saudi Arabia, Malaysia, India, South Africa, Canada, Australia, Russia, Spain, Greece, Pakiswait, Turkey, Egypt, Sudan, Uzbekistan, Philippines, and other countries.
♠Contacts information
♠Company information
As manufactures, we have more than 30 years of experience, our products all achieved patent certificates, and our company has many times achieved the title of honer: " Observe Contract and Keep Promise" " Quality Trustworthy Product" "Good After-sales Service Reputation", etc.
