Specifications
Coal slurry drying machine1.mainly for coal,coal slime,lignite coal
2.the moisture is 1-3%
3. can custom as your will
Coal slurry drying machine
Introduction of coal drying machine
Coal drying machine is a type of drying machine used to reduce the moisture of raw material, it is widely applied in building materials, metallurgy, chemicals, coal, fertilizer, sawdust industrials. it can accept almost all kinds of materials and can quick drying the materials. It is easy to operate and has large capacity. that is why this machine is so welcomed in every field.
Applicable scope
1.Chemical, mine, metallurgy industry, like ore, coal, metal power, clay, kaolinite.
2.Agriculture, forage, fertilizer Industry,such as straw, grasses, and sawdust and tree leaves, fish meal, corn,
rice, wheat, corn sauce, starch slag, vinasse, liquid, fruit dreg, soy sauce slag, peatmoss, organic compound fertilizer, sludge, aquatic products,slaughterhouses waste, organic fertilizer, inorganic phosphate fertilizer and ammonium sulfur.
Working principle of coal drying machine
1.This drying machine consists of rotary body, material plate, conveying device, supportive device, sealing
ring and other components.
2.Since the machine has a gradient, the materials enter the cylinder from its higher side. There is full of hot
gas in the cylinder, materials will be rolled by the metal plate inside up and down to accelerate the drying rate, then they will pushed to the lower side by the rolling device. The dried materials will be collected at the bottom.
Technical Parameters for coal slurry drying machine
model (m) |
diameter (cm) |
length (m) |
gradient |
rotate speed (r/m) |
weight |
power |
volume |
φ0.6×8 |
φ600 |
8 |
3-5 |
8 |
5.1 |
6-4 |
2.26 |
φ0.8×10 |
φ800 |
10 |
3-5 |
7.2 |
6.9 |
6-4 |
5.02 |
φ1.0×10 |
φ1000 |
10 |
3-5 |
6.73 |
7.5 |
6-5.5 |
7.85 |
φ1.2×12 |
φ1200 |
12 |
3-5 |
5.8 |
13.1 |
6-11 |
13.31 |
φ1.5×12 |
φ1500 |
12 |
3-5 |
4.8 |
22.3 |
6-15 |
21.2 |
φ2.2×14 |
φ2200 |
14 |
3-5 |
3.2 |
52.8 |
30 |
53.22 |
φ2.4×18 |
φ2400 |
18 |
3-5 |
3 |
73.3 |
37 |
81.43 |
φ2.8×24 |
φ2800 |
24 |
3-5 |
2.59 |
97 |
75 |
147.8 |
Pictures of coal drying machine
Customer visit production base
If you want to know more details of our coal dryer,welcome to contact me at any time! Skype:bojlantian Mob:0086-15038021962
