Specifications
E.P coal ball press machineLow energy consumption
campact structure
Easy debug and operation
coal ball press machine
Brief introduction:
The coal briquette press is used to press the hard molded dry powders into the various shaped briquettes. It has three parts spiral feeder, forming room and discharging device.
Working principle:
There are two rollers fixed in the frame.When they rotate the raw materials are put under the tremendous pressure. Under the pressure they will be squeezed into the various briquettes.
Made of 9Cr2Mo alloy steel and through heat treatment, the rollers have long application life. The shape of the briquettes is determined by the holes of the roller and it can be designed and produced according to your requirements.
Specification
Model |
Motor Power(kw) |
Diameter of Roller(mm) |
Capacity for Coal(t/h) |
Capacity for Coke(t/h) |
Capacity for Charcoal(t/h) |
Size( m³) |
HSYQ-450 |
22 |
450 |
5-7 |
5-7 |
2-2.8 |
1.65x1.5x2.40 |
Raw materials:
Some metal, mineral, coke, coal and charcoal powders.
Requirements for the raw materials:
1)size should be less than 3mm.
2) moisture should be less than 15%.
Final productions:
The final productions feature high density, high hardness through high pressure. And they also have the advantages of easy transportation and storage.
Any question pls contact me. It is our goal to offer the best service to you.
