Specifications
manufacture Bioenergy wood pellets machinery line1.CE approved
2.high yiled
3.low consumption
4.easy handle
manufacture Bioenergy wood pellets machinery line
Raw materials could be as following :
<1> Applicable materials: sawdust, rick husk, stalks, peanut shell, branches, etc.
<2> Moisture Content:Raw materials 12%-20%
<3>materials size:3-5mm
Making process as following:
It is often in this process: crushing wood chips---drying system---making pellets---cooling system--do the package
1. Crushing Process:
depending on the different input material, we fit out the suitable Crushing machines. If the raw material is big logs,
we need to split the log into small woods, and then are chipped into wood chips, our BX-Series Chipping and Crushing Machine is your best choices; While SFSW-series gear plate crusher is widely used to crush wood chips with high moisture into sawdust.
2. Drying Process:
The best moisture content to pelletizing is about 14-16%. Our new Air-Current Rotary Dryer is made up of Burning Stove and Main Rotary Dryer, which can realize to reduce the moisture
from 50% to 10%, and save about 30% energy consumption comparing the old Rotary Dryer.
3. Pelletizing Process:
Wood Pellet Machine is the most important equipment, which have the following features: This equipment use sawdust,
crops straw (corn stalk, beanstalk, sorghum culm and cotton stalk, rape stalk, sunflower culm and peanuts seedling),
the chaff, grass, shrubs, twigs, bamboo sawdust, bag asse as raw materials, use this machine high temperature extrude
into granules. Products are cylindrical.
4. Cooling Process:
After the pelletizing process, the temperature of the wood pellet is about 60-80 degree, and the moisture content of the wood pellet is about 15%, so we need use Cooler to reduce about 3-4% moisture, such this the wood pellet is easy to store.
5. Packing Process:
After cooling, the wood pellet will not directly enter into the fuel process, avoiding the wood pellet affected with
damp.The packing process is necessary.
Final pellets:
detail parameter for your reference:
Model |
Power |
Capacity |
Pellet size |
Weight |
Packing size |
HSKL-E120 |
3 kw |
70-100 kg/h |
2.5-12 mm |
80/100kg |
0.76*0.50*0.62M |
HSKL -E150 |
4 kw |
90-120 kg/h |
2.5-12 mm |
95/115kg |
0.75*0.35*0.65M |
HSKL -E200 |
7.5 kw |
200-300 kg/h |
2.5-12 mm |
200/230kg |
1.0*0.46*0.90M |
HSKL -E230 |
11 kw |
300-400 kg/h |
2.5-12mm |
290/320kg |
1.14*0.47*0.97M |
HSKL -E260 |
15 kw |
400-600 kg/h |
2.5-12 mm |
330/360kg |
1.2*0.5*1.07M |
HSKL -E300 |
22 kw |
600-800 kg/h |
2.5-12 mm |
420/450kg |
1.28*0.6*1.05M |
HSKL -E360 |
22 kw |
600-800 kg/h |
2.5-12 mm |
470/500kg |
1.29*0.56*1.06 |
HSKL -E400 |
30 kw |
900-1100 kg/h |
2.5-12 mm |
500/580kg |
1.52*0.6*1.15M |
About us :
Zhengzhou E.P machinery Co.,Ltd. was established to provide our customers with easy accesss to the finest Chinese
machines,such as Briquette Machines,Pellet Mill, Coal Machine and other equipment.Our staff members have rich
experience in knowing about China,its people and its products and we are proud of ourselves for our commitment
to quality reliability and speed.This is made possible with our careful combination and overseas experience in both
manufactury and trading areas.
More information, you are welcome to contact with us!
