Charcoal rod extruder machine
This charcoal rod extruder machine(or charcoal stick briquette machine) is the briquette machine to press the powder of coal, charcoal,carbon black and other materials into rods of certain intensity.
the shape of rods can be round, six prismatic, square and so on. Also the rod shape can be customized.
Working Principles of Charcoal Rod Extruder Machine :
the motor transfers the power to the transmission through triangle belt, then the output shaft on the
transmission transfers
the power to the propeller shaft, finally the propeller on the propeller shaft pushes the coal powder into
the mould and out, then the ideal high pressure coal rod is generated.
This process is very simple, and it's easy to operate.
Advantage of the charcoal rod extruder machine:
1.the charcoal bar pressed from the charcoal rod extruder machine is with high thermostability and
will not break into pieces in the process of burning.
2.The final briquettes are easy to transport and store.
It has high efficiency, energy saving and environmental protection
3.This charcoal rod extruder can also make shisha charcoal and sliver charcoal!
specifications of charcoal rod extruder machine:
Model |
Power |
Capacity(Ton/hr) |
reducer |
Weight(Ton) |
Packing size(M) |
HSLX-140 |
7.5/11 |
0.4-0.5 |
ZQ350 |
1 |
1.9*1.1*1.2 |
HSLX-180 |
18.5/22 |
1-1.2 |
ZQ400 |
1.6 |
2.1*15*1.2 |
HSLX-300 |
37 |
1.8-2.2 |
ZQ650 |
2.5 |
3.2*2.3*1.2 |
HSLX-450 |
45 |
3.5-4 |
ZQ850 |
5 |
3.6*2.6*1.3 |
More pictures of our charcoal briquette extruder:
