Help CenterHQ-LK 1.0 the Newest Best Biomass Wood Pellet Burner for Sale
Related Products
-
HQ-LK 1.0 Pellet Fired the Newest Wood Pellet BurnerUS$ 5,000 - 50,000MOQ: 1 Set -
Commercial Boilers With Biomass BurnerUS$ 5,000 - 50,000MOQ: 1 Set
-
New Product Biomass Burners for Industry BoilerUS$ 5,000 - 50,000MOQ: 1 Set
-
Energy-saving Sawdust Burner Biomass Wood ChipsUS$ 5,000 - 50,000MOQ: 1 Set
-
Biomass Sawdust Burner for 12ton/h Steam Boiler Thermal Oil HeaterUS$ 5,000 - 50,000MOQ: 1 Set
Specifications
1,Widely raw material2,PLC automatic control system
3,Environmental reach the standard
4,Safety micro negative pressure ope
HQ-LK Biomass Pellet Burner
The advantage of biomass burner
Teach advantage: Full automatic feeding;
High temperature pyrolysis
Suspension and multistage air increasing,
PLC control,
Interconnection and interlocking
Energy-saving advantage:
Fuel coal boiler can save energy 30-40%
Fuel oil boiler can save energy 50-70%
Environment advantage:
Trace SO2,CO2 emission,ash<about 1.5%
ROI: Fuel coal boiler can recovery within 2-3 months
Application range:apply to any energy needed enterprise
The material
Application scope
Details
The Parameters
|
Model Item |
Conveyor motor power(kw) |
Motor power of feeder (kw) |
Automatic ash delivery motor power(kw) |
Air fan power (kw) |
Size of main burner(mm) |
HQ-LK0.5 |
1.1 |
0.75 |
/ |
1.5 |
1800*900*1500 |
HQ-LK1.0 |
1.1 |
1.1 |
/ |
2.2 |
2400*2200*1550 |
HQ-LK1.5 |
1.5 |
1.5 |
/ |
2.2 |
2400*2400*1800 |
HQ-LK2.0 |
2.2 |
1.5 |
0.75 |
4 |
2400*2400*2000 |
HQ-LK3.0 |
2.2 |
1.5 |
0.75 |
5.5 |
2600*2500*2200 |
HQ-LK4.0 |
3 |
1.5 |
1.5 |
5.5 |
2600*2600*2350 |
System flow chart(connect with boiler)
biomass burner videos
l Specifications of biomass energy and other energy comparison table:(take 1000kg/h steam boiler as an example)
Boiler equipments |
Material consumption |
Unit price of fuel |
Operation cost |
|
Light diesel oil boiler |
66Kg |
6.3RMBKg
|
415.8RMB |
Heavy oil boiler |
70Kg |
4.5RMBKg |
315RMB
|
|
Natural gas boiler
|
79.3Nm³ |
3.5RMB/Nm³ |
278RMB |
|
Electricity boiler
|
720Kg |
1.2RMB/kwh |
864RMB |
|
Biomass burner
|
145Kg |
1.0RMB/Kg |
145RMB |
Our company
Certification
Service Concept
Pre-sale service
Provide professional suggestion from corresponding pre-sale service engineers and consulting service, customized design solution.
After-sale service
First time installation or commissioning train operators service available home or abroad, technical service
Tracking service
Build customer service database ,track sawdust burner working per
