Popular 0-5PPM Ozone Generator Detector / Ozone Gas Sensor

Popular 0-5PPM Ozone Generator Detector / ozone gas sensor

CH-8318

Introduction:

1. CH-8313 Portable O3 gas analyzer is a hand-held instrument which can continually test O3. This product is applicable to environmental monitoring, industrial production, chemical and other occasions with O3, can effectively guarantee the safety of staff from abuse and loss of production equipment.

2. O3 detector adopts diffused detection methods; adopt Switzerland MEMBRAPOR electro-chemical sensors as sensitive sensors, have excellent sensitivity and repeatability; TI Low-power microprocessor, high reliability; excellent man-machine interface is not only done a full-featured and easy to operate. 128*64 Liquid crystal display, Clear display, its compact design and attractive appearance and comfortable feel is the best choice for handheld applications.

3. CH-8313 Series Portable O3 Gas Detector is widely used in Electronics, petroleum, petrochemical, chemical, metallurgy, electric power and other industrial and civilian environment.

Features:

1. Adopt advanced 16 bits controller of Ultra-low power

2. Resolution is 128*64 LCD screen

3. High-precision electro-chemical sensors

4. Can be set high /low alarm point, two levels sound and light alarm.

5. Provide calibration methods of software and hardware calibration, concentration can be adjustable.

6. Provide real-time clock display

Specifications:

Applicable of gas : O3(0—5 PPM)

Sensor type: Electro-chemical

Sampling way : Diffused

Precision : 0.02 PPM

Response time: T90<60S

Indicate way: LCD display real-time concentration , LED, buzzer alarm .

Operate environment: --10℃—50℃ 15%-95%RH(Non-condensing)

Operate voltage: DC3.7V  Lithium: 1100mAh

Charge time: 6-8 hours

Continuous work hours: 30 hours above , Sensor life: 1 year

Popular 0-5PPM Ozone Generator Detector / ozone gas sensor

Application:Ozone gas tester
